The core board has a total of four high-speed expansion ports. It uses four
120-pin inter-board connectors (J29~J32) to connect to the carrier board. The
connector uses the Panasonic AXK5A2147YG, and the connector type
corresponding to the carrier board is AXK6A2337YG. J29 connects BANK12 IO
and BANK13 IO, J30 connects GTX transceiver signal, J31 connects JTAG and
BANK35 IO (1.8V level standard), J32 connects PS MIO, BANK13 IO and +5V
power supply
Pin assignment of J29 connector
J29 Pin Signal Name
1 B13_L8_P
3 B13_L8_N
5
7 B13_L10_N
9 B13_L10_P
11
13 B13_L15_N
15 B13_L15_P
17
19 B13_L23_N
21 B13_L23_P
23
25 B13_L22_P
27 B13_L22_N
29
31 B13_L17_N
33 B13_L17_P
25 / 33
ZYNQ FPGA Development Board AC7Z035 User Manual
Board to
ZYNQ Pin
Number
AE23
AF23
GND -
AA23
AA22
GND -
AF20
AF19
GND -
W19
W18
GND -
AA19
AB19
GND -
AD19
AD18
Amazon Store: https://www.amazon.com/alinx
Board Connectors
J29 Pin Signal Name
2 B13_L9_N
4 B13_L9_P
6 GND
8 B13_L13_N
10 B13_L13_P
12 GND
14 B13_L14_N
16 B13_L14_P
18 GND
20 B13_L7_P
22 B13_L7_N
24 GND
26 B13_L20_P
28 B13_L20_N
30 GND
32 B13_L18_N
34 B13_L18_P
pin
ZYNQ Pin
Number
AB22
AB21
-
AD21
AD20
-
AC22
AC21
-
AE22
AF22
-
AA20
AB20
-
AF18
AE18
