Part 5: eMMC Flash

The FPGA core board AC7Z035 is equipped with a large-capacity 8GB
eMMC FLASH chip, model THGBMFG6C1LBAIL, which supports the JEDEC
e-MMC V5.0 standard HS-MMC interface with level support of 1.8V or 3.3V.
The data width of the eMMC FLASH and ZYNQ connections is 4 bits. Due to
the large capacity and non-volatile nature of eMMC FLASH, it can be used as a
large-capacity storage device for the ZYNQ system, such as ARM applications,
system files and other user data files. The specific models and related
parameters of eMMC FLASH are shown in Table 5-1.
Position
U11
eMMC FLASH is connected to the GPIO port of the BANK501 in the PS
section of the ZYNQ chip. In the system design, the GPIO port functions of
these PS ports need to be configured as the SD interface. Figure 5-1 shows the
eMMC Flash in the schematic.
16 / 33
ZYNQ FPGA Development Board AC7Z035 User Manual
ZYNQ Pin Name
PS_MIO6_500
PS_MIO1_500
PS_MIO2_500
PS_MIO3_500
PS_MIO4_500
PS_MIO5_500
PS_MIO9_500
PS_MIO0_500
PS_MIO10_500
PS_MIO11_500
PS_MIO12_500
PS_MIO13_500
Model
THGBMFG6C1LBAIL
Table 5-1: eMMC FLASH Specification
