HLX-24 Quick Reference
2.2

The Keypad

Figure 2 shows the HLX-24 keypad.
Table 2 describes the keypad functions:
Key
Panic
Keys 0 – 9
Arm Away
Arm Home
Disarm
ESC/Back
Enter
Up/Down Arrows
12

Figure 2: HLX-24 Keypad

Table 2: Keypad Functions

Icon
HLX-24 Hardware Installation and Programming Manual
Function
When pressed for 3 seconds a standard
panic alarm sounds
Enters alphanumeric entries
Press 0 to enter a space
Arms all sensors and detectors for use
when there is no one at home/office
Arms all perimeter sensors and detectors
as defined by the installer (for use when
home/office is occupied)
Disarms all armed sensors and detectors
Ignores an entry or moves one level up in
a menu
Accepts an entry or selection
Use to navigate between menus
