HLX-24 Quick Reference
2.3

Sound Indicators

Table 4 presents the sounds emitted by the system and push buttons if
enabled during programming.
Sound
Single beep
Long Beep
Three short beeps
Four short beeps a
minute
Short beep every
second
Chime
This table does not include actual alarm sounds.
Note that the audible indication of a fire zone differs from that of a normal
intrusion zone.
2.4

LED Indicators

Table 5, Table 6, and Table 7 describe the LED indicators of the various panel
indicators.
Power LED
(Red/Green)
Green ON
FLASHES red every 0.5 seconds AC Failure
Status LED
(Red/Green)
Green ON
Red ON
Green FLASHES every 1 second Walk Test mode
14

Table 4: Sound Indicators

Sounded when
A key is pressed
There is an illegal key entry
An entry is successfully accepted
If enabled, on trouble condition
An exit/entry delay is activated (beep sounded every 0.5
seconds during last 10 seconds of delay)
When feature is activated (1 chime sounds)

Table 5: Power LED Indicator

Status
Normal AC mode

Table 6: Status LED Indicator

Status
Panel ready
Panel not ready
HLX-24 Hardware Installation and Programming Manual
