Installer Menu
4. Press Enter to access the desired submenu to define several characteristics
as follows:
Zone Type: Select one of the following:

 Delay – An opening in this zone is alarmed only after the exit or
entry time has passed
Fire – An opening in this zone causes a fire alarm and is armed

24 hours a day
24H Silent – An opening in this zone causes a silent alarm (no

audible local siren) and is armed 24 hours a day
 24H Audible – An opening in this zone causes an audible alarm
and is armed 24 hours a day
 No Secure – non-alarm zone – zone can be used for any non-
secured propose
 Interior – Zone is bypassed when system is in Arm Home (Stay)
mode
 Interior Follow – A non-entry/exit zone, typically an interior zone
located on an entry/exit path, which is treated as an entry/exit
zone during an Entry Delay or Exit Time. An opening in this zone
is alarmed only after the exit or entry time has passed.
 Perimeter – Zone is armed both in Arm Home and Arm Away
modes
Description: Select one of 38 fixed descriptions or one of five

editable custom descriptions. HLX-24 enables you to specify five
custom zones (see Section 6.7.3).
For your convenience and better control of the installation, use the
tables provided in Appendix C.
 No Activity: Select to enable or disable the no activity time for each
zone. When there is no activity in the specified zone and the system
is disarmed, a silent alarm is sent to the monitoring station. When the
system is armed and there is no activity in the specified zone, an
audible alarm and a report are sent to the monitoring station. By
default the option is disabled.
Swinger: Select the number of repeated opening events from the

zone after which the system ignores the zone. The default setting is 2
zone openings. The zone is restored after a manual system reset or
automatically after a defined number of hours. The default value is 8
hours.
Zone cross: The zone cross option requires an opening of two zones

within a given time period to initiate an Alarm event sequence. This
setting links between the two zones.
