MRX
11.4.3.6 Importing a profile
Profiles (in binary format) or ASCII configuration files can be uploaded to the router
in the "Administration" menu on the
You need to locate the respective file on the computer under "Import profile or
ASCII configuration file" for this. The profile will be uploaded with a click on the
button "OK" and it appears in the respective list.
11.4.3.7 Deleting a profile
A stored profile can be deleted in the "Administration" menu on the "Profiles" page
by clicking the button with the recycle bin symbol
11.4.3.8 Comparing two profiles
To show the differences between two profiles, it is possible to compare the default
settings, the running profile and the stored profiles to each other.
For this, you need to select the two profiles to be compared in the "Administration"
menu on the "Profiles" page under "Compare profiles". The different settings of
both profiles are displayed side by side when clicking the button "OK".
Figure 53: Profile handling – scheme
11.4.4

ASCII Configuration

ASCII configurations are a sequence of commands as they could also be entered in
the CLI. Each line contains a command that modifies the opened profile.
Syntax and parameters can be taken from a downloaded profile in ASCII format for
example. Refer to the CLI description for further information about the syntax.
Commands that affect plug-in cards that are not installed will be taken over to the
profile, but will have no effect.
Profiles" page.
"
behind the respective profile.
Operating Principle
87
