Profiles and Profile Handling

The configuration of the router is called profile. Several profiles can be stored on
one device so that the configuration of a device can be changed quickly.
11.4.1

Term definitions

The following terms or conditions are to be distinguished for profiles:
• running:
• opened:
• last activates, changed: the last activated profile that differs from the
• stored:
Simple applications do not require the use of more than one profile. However, the
router allows many applications by using several profiles. From risk-free testing of
modified configurations up to time- or event-triggered switching of different pro-
files, there are almost no limits for your application.
If the running profile differs from the opened profile, this will be indicated by the
appearance of a blinking gear symbol
Following an intentional or unintentional restart of the router (e.g. power supply in-
terruption), the previously running profile will continue to run and the last activated
profile will be opened again. If they differ, the button with the gear symbol
blinks again.
11.4.2

Working with one profile

If only one profile is used, the current (opened) profile can be configured in the web
interface. Settings made in the opened profile are stored in this profile with a click
on the button "OK". They will not become effective in the running profile with this.
If the current profile has been modified, the blinking gear symbol
the title bar. A click on the button with the blinking gear symbol
opened profile, i.e. it becomes the running profile and the modifications of the
router configuration become effective. The gear symbol will disappear.
Figure 52: Profile handling – activating configuration modifications
the current configuration of the router which is used for
operation at the moment
the profile that is currently displayed in the web interface (or CLI
or REST interface) for editing
running profile by subsequent changes
one of several possible profiles that are stored on the router by
the user
with the button "Activate profile".
