  • Page 1 INSYS GSM 4.3...
  • Page 3 Copyright © August 11 INSYS MICROELECTRONICS GmbH Any duplication of this manual is prohibited. All rights on this documentation and the devices are with INSYS MICROELECTRONICS GmbH Regensburg. Trademarks The use of a trademark not shown below is not an indication that it is freely avail- able for use.

  • Page 4: Table Of Contents

    Front Panel Connections..................26 Terminal Connections on the Top ................27 Terminal Connections on the Bottom ..............28 Pin Assignment of the Serial Interface..............29 Audio Connection (not INSYS GSM 4.3 compact) ..........29 Mounting ....................30 Initial Operation..................34 Operating Principle ................36 11.1 Operation via Terminal Program ................36 11.2 Operation via SMS....................37...
  • Page 5 12.8 Configure Dial-Up Attempts for Message Dispatch ..........50 12.9 Configure Scheduled Logout/Login ..............50 12.10 Establishing or Accepting a Data Connection ............52 12.11 Establish Voice Connection (not INSYS GSM 4.3 compact) ........54 12.12 Using USSD Codes....................54 12.13 Idle Connection Control with Data Transmit Control ...........55 12.14 Automatic Call Acceptance..................56...
  • Page 6 Content GSM Service Center Numbers ...............88 Waste Disposal ..................89 16.1 Repurchasing of Legacy Systems................89 Declaration of Conformity ..............90 Tables and Diagrams................91 18.1 List of Tables .......................91 18.2 List of Diagrams ....................91 Index......................92 Aug-11...

  • Page 7: Preface

    INSYS GSM 4.3 Preface Preface This manual allows for the safe and efficient use of the product. The manual is part of the product and must always be stored accessible for installation, commission- ing and operating personnel. Defects Liability Terms...

  • Page 8: Marking Of Warnings And Notes

    Preface INSYS GSM 4.3 Marking of Warnings and Notes 1.2.1 Symbols and Key Words Danger! Risk of severe or fatal injury One of these symbols in conjunction with the key word Danger indicates an imminent danger. It will cause death or severe injuries if not avoided.

  • Page 9: Symbols And The Formatting In This Manual

    INSYS GSM 4.3 Preface Symbols and the Formatting in this Manual This section describes the definition, formatting and symbols used in this manual. The various symbols are meant to help you read and find the information relevant to you. The following text is structured like a typical operating instruction of this manual.

  • Page 10: Safety

    Safety INSYS GSM 4.3 Safety The Safety section provides an overview about the safety instructions, which must be observed for the operation of the product. The product is constructed according to the currently valid state-of-the-art technol- ogy and reliable in operation. It has been checked and left the factory in flawless condition concerning safety.

  • Page 11: Permissible Technical Limits

    INSYS GSM 4.3 Safety Permissible Technical Limits The product is only intended for the use within the permissible technical limits specified in the data sheets. The following permissible limits must be observed:  The ambient temperature limits must not be fallen below or ex- ceeded.

  • Page 12: Markings On The Product

    Safety INSYS GSM 4.3 Markings on the Product The identification plate of the product is either a print or a label on a face of the product. Amongst other things, it contains the following markings, which are ex- plained in detail here.

  • Page 13: Safety Instructions For Electrical Installation

    INSYS GSM 4.3 Safety Safety Instructions for Electrical Installation The electrical connection must only be made by authorised expert personnel ac- cording to the wiring diagrams. The notes to the electrical connection in the manual must be observed. Otherwise, the protection category might be affected.
  • Page 14 Safety INSYS GSM 4.3 Caution! Overvoltage and voltage peaks from the mains supply! Fire hazard and damage of the product due to overvoltage. Install suitable overvoltage protection. Caution! Damage due to chemicals! Ketones and chlorinated hydrocarbons dissolve the plastic housing and damage the surface of the device.

  • Page 15: Scope Of Delivery

    Scope of Delivery Scope of Delivery The scope of delivery for the INSYS GSM 4.3 includes all accessories listed below. Please check if all accessories are included in the box. If a part is missing or dam- aged, please contact your distributor.

  • Page 16: General

    INSYS GSM 4.3. Both versions are referred to as INSYS GSM 4.3 in the further course of this manual. If the INSYS GSM 4.3 compact differs from the INSYS GSM 4.3, this will be mentioned in par-...

  • Page 17: Functional Overview

    The INSYS GSM 4.3 offers the following functions:  Data buffer for serial data transmission The INSYS GSM 4.3 has a fast send and receive buffer (cache) to ad- just the modem to the operating speed of the application.  Hardware and software data flow control The INSYS GSM 4.3 can transmit to the application via the control...
  • Page 18  Pulse output via switching outputs The switching outputs can be opened and closed sequentially. This enables to output so-called „counting pulses“ at the outputs of the INSYS GSM 4.3. The INSYS GSM 4.3 can output up to ten pulses per output.
  • Page 19 New functions of the INSYS GSM 4.3:  Switching the outputs by establishing a modem connection The INSYS GSM 4.3 can change the state of a switch output by estab- lishing a modem connection (enabling of the control line DCD). This enables your application to react on such events.

  • Page 20: Technical Data

    Weight 270 g (INSYS GSM 4.3) 218 g (INSYS GSM 4.3 compact) Dimensions (Width x Depth x Height) 55 x 110 x 75 mm (INSYS GSM 4.3) 82 x 58 x 84 mm (INSYS GSM 4.3 compact) Temperature range 0 °C – 55 °C (INSYS GSM 4.3) -20 °C –...

  • Page 21: Technological Features

    INSYS GSM 4.3 Technical Data Technological Features Technological Feature Description Data formats of the serial interface 7E1,7O1, 7N2, 8N1, 8E1, 8O1, 8N2, Supported GSM audio encoding HR,FR,EFR Fax-Classes Fax Class 1/2 Modulation types V.22bis, V.32, V.34,V.23, V.110 Table 2: Technological Features...

  • Page 22: Display And Control Elements

    Display and Control Elements INSYS GSM 4.3 Display and Control Elements Figure 1: Control elements/displays (INSYS GSM 4.3) Figure 2 Control elements/displays (INSYS GSM 4.3 compact)
  • Page 23 INSYS GSM 4.3 Display and Control Elements Position Description Power LED Status LED Connect LED / DCD LED (INSYS GSM 4.3 compact) RX/TX LED Signal LED SIM card holder SIM card holder eject key Reset key Table 3: Description of the LEDs on the front panel of the device...

  • Page 24: Meaning Of The Displays

    Power LED LED on Supply voltage available LED off No supply voltage Status LED LED on INSYS GSM 4.3 is logged in into the cellular network LED flashes Data connection estab- lished LED flashes quickly Initialization, SMS dis- patch, alarm processing LED off INSYS GSM 4.3 is not...

  • Page 25: Function Of The Control Elements

    Function of the Control Elements Description Operation Meaning Reset key Press at least 1 second. Resets the INSYS GSM 4.3 and restarts it. Press at least 25 seconds Resets the INSYS GSM 4.3 (you may release if the to factory defaults and re- Connect or DCD and starts it.

  • Page 26: Connections

    Connections Front Panel Connections Figure 3: Connections on the front panel of the device (INSYS GSM 4.3) Figure 4: Connections on the front panel of the device (INSYS GSM 4.3 compact) Position Description Audio connection (audio socket, not INSYS GSM 4.3 compact)

  • Page 27: Terminal Connections On The Top

    INSYS GSM 4.2 INSYS GSM 4.2 compact Figure 5: Connections on the top of the device Terminal Name Description Ground (not INSYS GSM 4.3 compact) Reserved (not INSYS GSM 4.3 compact) 10 ... 60VDC Power supply 10V - 60V DC Ground Ground...

  • Page 28: Terminal Connections On The Bottom

    Connections INSYS GSM 4.3 Terminal Connections on the Bottom OUT 1-NC OUT 1 OUT1-NC OUT1 OUT 1-NO OUT1-NO OUT 2-NC OUT2-NC OUT 2 OUT2 OUT 2-NO OUT2-NO INSYS GSM 4.2 INSYS GSM 4.2 compact Figure 6: Description of the connections on the top of the device...

  • Page 29: Pin Assignment Of The Serial Interface

    Ground Data set ready Request to send Clear To Send Ring Indication Table 10: Description of the pin allocation of the D-Sub jack Audio Connection (not INSYS GSM 4.3 compact) Signal Description Microphone - Speaker - Speaker + Microphone +...

  • Page 30: Mounting

    INSYS GSM 4.3 Mounting This section describes how to mount the INSYS GSM 4.3 to a DIN rail, con- nect the power supply and uninstall it again. Observe the instructions in the "Safety" section of this manual, in particular the "Safety Instructions for Elec- trical Installation"...
  • Page 31 Position the device at the DIN rail as seen in the following diagram. There are two snap-in hooks at the upper and lower edge of the DIN rail groove of INSYS GSM 4.3. Hook the upper one into place behind the upper edge of the DIN rail.
  • Page 32 The INSYS GSM 4.3 is disconnected from the power supply. Uninstalling the device from the DIN rail How to uninstall the INSYS GSM 4.3 from a DIN rail in a switch cabinet:  You will need a Phillips screwdriver with a 4.5 mm blade.
  • Page 33 While you hold the plastic spring apart with the lower snap-in hooks, pull the INSYS GSM 4.3 away from the DIN rail. Un-hook the INSYS GSM 4.3 and take it off perpendicularly to the DIN rail.  The INSYS GSM 4.3 is now removed.

  • Page 34: Initial Operation

    Initial Operation This chapter describes how to commission the INSYS GSM 4.3, i.e. how to connect the INSYS GSM 4.3 to a PC, to log it into a mobile phone network, and how to test it. Connect the INSYS GSM 4.3 to a PC How to connect the INSYS GSM 4.3 to a PC via a serial interface.
  • Page 35  The RX/TX LED light up while you type.  If the RX/TX LED at the INSYS GSM 4.3 does not light up, while you type AT an d receive an , the reason may be that you are connected to another modem (e.g.

  • Page 36: Operating Principle

    Operating Principle This chapter describes the basic procedures for operating and configuring a INSYS GSM 4.3. It will also give you an overview of the control elements of the software HSComm. You have several possibilities to operate and configure the INSYS GSM 4.3. In gen- eral, the INSYS GSM 4.3 is configured and operated via AT commands.

  • Page 37: Operation Via Sms

    Save your entries with  Not all settings at the INSYS GSM 4.3 must be actively stored by en- tering AT&W. Some settings are automatically saved immediately. We still recommend sending the command AT&W to the INSYS GSM 4.3 as your last configuration step to ensure that all settings are stored safely and are available for the next restart.

  • Page 38: Operation With Hscomm Gsm

    If this option is not activated, the settings can be read out with the Read settings button in the fi eld on the right.  The program will now search for a connected INSYS GSM 4.3 and w attempt to read the se ttings. ...
  • Page 39 Afterwards, click on the button Send settings in the field on the right.  A progress bar appears above the button.  The entered settings are sent to the INSYS GSM 4.3 and stored.  A dialog box with the message "transmission finished" is displayed. Click OK in the status message.

  • Page 40: Functions

    Entering the PIN of the SIM Card The INSYS GSM 4.3 requires a SIM card to be able to log into a GSM network. Usually, a PIN is necessary that the device is able to use the SIM card for logging into the GSM network.
  • Page 41 INSYS GSM 4.3 Functions In order to check the status of the PIN re- AT+CPIN? quest between device and SIM card, use the command The following replies inform about the status of the PIN request: READY No entry required SIM PIN...

  • Page 42: Inserting And Removing The Sim Card

    12.2 Inserting and Removing the SIM Card A SIM card must be inserted that your INSYS GSM 4.3 is able to log into the GSM network and transmit data. Moreover, the PIN of the SIM card must be entered into the INSYS GSM 4.3.
  • Page 43 INSYS GSM 4.3 Functions Remove SIM card How to remove the SIM card from the INSYS GSM 4.3.  You will need a pointed tool, e.g. a ball pen refill. Disconnect the power supply of the INSYS GSM 4.3. Press onto the SIM card holder eject key using the pointed tool.

  • Page 44: Checking The Status Of The Gsm Login

    The login status into the GSM network may be requested for test purposes. Then, you can see, whether the INSYS GSM 4.3 is logged out at the moment, whether a network search is performed, whether a login has been re- fused by the GSM network, or whether the device is logged in into a foreign net- work via roaming.

  • Page 45: Checking The Signal Field Strength Of The Mobile Phone Network

    Checking the Signal Field Strength of the Mobile Phone Network You can check the signal field strength at the location of the INSYS GSM 4.3. The signal field strength has an essential effect on the data transmission speed. If the signal field strength is too low, the transmission speed may drop too much or the connection may be terminated completely.

  • Page 46: Configure Serial Interface

    INSYS GSM 4.3 and the interface at the PC or the application must match exactly, that data can be transmitted successfully.

  • Page 47: Data Flow Control (Handshake)

    When the buffer is emptied sufficiently for the INSYS GSM 4.3 to be able to receive data again, the CTS line is set to "high". Reversely, the application can also indicate to the INSYS GSM 4.3 to inter- rupt the data flow.

  • Page 48: Software Data Flow Control (Xon/Xoff)

    Functions INSYS GSM 4.3 12.6.2 Software Data Flow Control (XON/XOFF) When the input buffer of the modem exceeds a certain fill state, the modem will insert an XOFF character into the data stream to the application. This character will cause the application to send no more data. It will depend on the according appli- cation software if the XON/XOFF data flow control is supported.

  • Page 49: Configure Date And Time

    “Date/Time” panel the drop-down menu “date” as well as the spinner “time”. In order to take over the time of your PC into the INSYS GSM 4.3, click the “System clock (PC)” button. Store your settings in the INSYS GSM 4.3 by clicking the “Send settings”...

  • Page 50: Configure Dial-Up Attempts For Message Dispatch

    12.9 Configure Scheduled Logout/Login The INSYS GSM 4.3 can logout from the GSM network at a scheduled time for a configurable period. This function serves for increasing the availability and ubiquity of the INSYS GSM 4.3 for a longer period.
  • Page 51 The logout is performed later in both cases, if the logout time interferes with an SMS dispatch or if a data connection to the INSYS GSM 4.3 is established. The scheduled logout/login will only be performed, if the SMS has been sent or an ex- isting data or audio connection has been terminated.

  • Page 52: Establishing Or Accepting A Data Connection

    GSM network. This is usually 9600 bit/s. The speed, which is set at the serial interface of the INSYS GSM 4.3 at the time of connection establishment, will not be changed.
  • Page 53 In order to change to command mode during a data connection, use the escape sequence No data must be transmitted for 1 second be- fore and after that the INSYS GSM 4.3 changes to command mode. In order to change from command mode to...

  • Page 54: Establish Voice Connection (Not Insys Gsm 4.3 Compact)

    In order to be able to use the voice functionality, you need to connect a standard phone receiver into the audio socket of the INSYS GSM 4.3. During dialling, an acoustic signal in form of a tone sequence can be heard in the receiver.

  • Page 55: Idle Connection Control With Data Transmit Control

    The DTC function can define the time after which the INSYS GSM 4.3 will hang up as soon as there is no data transfer on the phone line. Configuration with HSComm In order to enable Data Transmit Control, enter the time, after which the INSYS GSM 4.3 shall hang up in case of missing data transmission on...

  • Page 56: Automatic Call Acceptance

    The INSYS GSM 4.3 will iden- tify the caller via CLIP. This must, however, be supported by the network provider. The list of phone numbers of the INSYS GSM 4.3 for identifying the callers has 30 storage locations altogether.
  • Page 57 “GSM Connection” panel the check box “auto answer” first. Enter the desired number of ring tones, after which the INSYS GSM 4.3 picks up, into the entry field “number of rings before answer”. Activate on the “Access Control” tab on the “CLIP Numbers” panel the check box “only calls from the following numbers are accepted”.

  • Page 58: Configure Security Callback

    INSYS GSM 4.3 12.16 Configure Security Callback The function “Security Callback” allows that a call at the INSYS GSM 4.3 initiates a call to a pre-defined phone number. The function will trigger a callback after suc- cessful authentication using a password. The password is absolutely necessary for the security callback.
  • Page 59 Triggering a "Security Callback" How to trigger a security callback of the INSYS GSM 4.3:  You will need another modem or another INSYS GSM 4.3 to be able to es- tablish a connection to the INSYS GSM 4.3. ...

  • Page 60: Alarm Inputs

    SMS, or establish a voice connection. The INSYS GSM 4.3 will evaluate a connection of the input to GND as a pulse. This will only consider a falling edge. Two “pulse types” are available: “simple pulses”...

  • Page 61: Configure Alarms

    The INSYS GSM 4.3 can react with the dispatch of an alarm message on switch events using its digital inputs. The INSYS GSM 4.3 uses a single, long pulse or a sequence of short pulses to trigger the message dispatch. The INSYS GSM 4.3 can establish a voice connection as an alternative to the single message dispatch via the single pulse.
  • Page 62 In order to establish a voice connection to a specified phone number in case of an alarm at the input, select on the “Alarm” tab for the respective alarm input of the INSYS GSM 4.3 “single alarm” in the drop-down list “alarm trigger”. Select “voice” as medium for the alarm transmission via the drop-down list “alarm transmission by”.
  • Page 63 INSYS GSM 4.3 Functions In order to enter the messages, use the command Replace <in> with the number of the input, to which the alarm message is to be as- signed, <n> with the index number 0-10 of the alarm message, and <text> with the alarm message text.

  • Page 64: Switching Outputs

    INSYS GSM 4.3 12.19 Switching Outputs The INSYS GSM 4.3 has two switching outputs, OUT1 and OUT2. They can be con- trolled individually via AT commands, which can be transmitted to the INSYS GSM 4.3 via a terminal program or SMS. Besides this, the INSYS GSM 4.3 can switch...
  • Page 65 INSYS GSM 4.3 Functions Configuration with AT commands In order to configure the outputs, use the command Replace the parameters as follows: <output> with 1 for control output 1 2 for control output 2 if the information is missing, output 2 is used <man>, manual activation (AT/SMS/DTMF)

  • Page 66: Switch Command For Controlling The Control Outputs

    (switch alias). The clear text commands can then be transmitted to the INSYS GSM 4.3 via terminal program or SMS, to execute the respective switch operations. For this, the clear text names must be assigned to the respective SWITCH command before.

  • Page 67: Activate Switching / Querying Of The Outputs / Inputs Via Dtmf

    12.20 Activate Switching / Querying of the Outputs / Inputs via DTMF The outputs at the INSYS GSM 4.3 can be switched via the DTMF tones of a con- ventional telephone. The inputs can also be queried via DTMF tones. The input states as well as the responses of the switching processes will be transformed acoustically into tone sequences of well differentiated high and low tones.
  • Page 68  If the DTMF processing is enabled, automatic call acceptance does not have to be enabled explicitly, because the INSYS GSM 4.3 accepts voice calls automatically in any case. Switching and querying the outputs and inputs via DTMF can be protected with the optional DTMF PIN.
  • Page 69 INSYS GSM 4.3 Functions Configuration with AT commands In order to set the PIN, use the command AT**PASST=<newPIN>, <newPIN> Replace <newPIN> with the PIN and with the repetition of the PIN. In order to change the PIN, use the com- mand AT**PASST=<oldPIN>,...

  • Page 70: Switching The Outputs / Querying The Inputs Via Dtmf

    INSYS GSM 4.3 12.21 Switching the Outputs / Querying the Inputs via DTMF This section describes how the outputs of the INSYS GSM 4.3 can be switched or pulsed with the help of the DTMF tones of a conventional tele- phone.
  • Page 71  If the wrong DTMF PIN has been entered, you will hear the acoustic signal for “Error” and the INSYS GSM 4.3 hangs up. Return to step 2. Switching the outputs How to switch the outputs of the INSYS GSM 4.3 via DTMF.
  • Page 72 Press the key "*" at the phone.  The INSYS GSM 4.3 will output its input states. First input 1, then in- put 2. For the HIGH state, a long, high ton is produced; for the LOW state a low, long to...

  • Page 73: Remote Configuration Of The Insys Gsm 4.3

    In order to configure the INSYS GSM 4.3 remotely, a data connection with the IN- SYS GSM 4.3 to be configured must be established. This can be achieved by a call with any modem at the INSYS GSM 4.3. After changing into remote configuration mode, AT commands for configuring the INSYS GSM 4.3 can be transmitted.
  • Page 74 Functions INSYS GSM 4.3 In order to change the password, use the command AT**PASSC=<oldPW>,<new Replace <oldPW> with the current pass- PW>,<newPW> word, <newPW> with the new password and with the repetition of the new password. In order to delete the password, use the command AT**PASSC=<oldPW>...
  • Page 75  You will need a terminal program. Open your terminal program. Establish a connection to the INSYS GSM 4.3. Use the local modem to dial the phone number of the INSYS GSM 4.3 with ATD<phonenumber>.  The local modem establishes a connection.

  • Page 76: Configure Remote Configuration Via Sms

    12.23 Configure Remote Configuration via SMS You are able to send the extended INSYS AT** commands to the INSYS GSM 4.3 via SMS as well. The commands sent via SMS will be executed as soon as the INSYS GSM 4.3 is in command mode. ...
  • Page 77 INSYS GSM 4.3 Functions In order to change the password, use the command Replace <oldPW> with the current pass- AT**PASSC=<oldPW>,<new PW>,<newPW> word, <newPW> with the new password and with the repetition of the new password. If you do not enter a new password, the...

  • Page 78: Configure Periodic Alive Message

    Functions INSYS GSM 4.3 12.24 Configure Periodic Alive Message The INSYS GSM 4.3 can send an alive message daily, weekly, or monthly as SMS message to a specified phone number. Configuration with HSComm In order to configure the dispatch of a periodic alive message, enter on the “Basic Settings”...

  • Page 79: Configure Power-Up Sms

    Functions 12.25 Configure Power-Up SMS If this function is enabled, the INSYS GSM 4.3 sends an SMS after each interrup- tion of the power supply for more than 5 seconds (not reset). The INSYS GSM 4.3 adds date and time to the power-up SMS.

  • Page 80: Manual Sending Of Messages

    The INSYS GSM 4.3 can be operated at a programmable logic controller. Settings recommended by INSYS for a INSYS GSM 4.3, which is used at the PC to commu- nicate with the PLCs, are available for certain controllers. The respective configura- tion files can be found under http://www.insys-tec.de/en/en/plc/ or in the “Configu-...

  • Page 81: Event History

    INSYS GSM 4.3 Functions 12.28 Event History The INSYS GSM 4.3 provides a history function to record events. This takes up to 200 entries chronologically as circular buffer (FIFO), i.e. the oldest messages are overwritten in case of more than 200 entries.
  • Page 82 Functions INSYS GSM 4.3 Reason Detail Description RTC ERROR Internal real time clock empty (time stamp empty) Internal real time clock has been reset since the goldcap was RTC RESET discharged (power reserve exhausted) time stamp: 00:00:00 01.01.03 Instruction from controller to GSM engine could not be proc- GSM ERROR essed correctly (e.g.

  • Page 83: Reset Of The Device

    GND terminal for at least 25 seconds, as well as by using an AT command or the HSComm software. Configuration with HSComm To restart the INSYS GSM 4.3, click on the button “Reset” in the field on the right. To reset the INSYS GSM 4.3 to factory defaults, click on the button “Send default settings”...

  • Page 84: Firmware Update

    They will provide you with the suitable firmware version for your INSYS GSM 4.3. The firmware of the INSYS GSM 4.3 can be updated to add more functions to the INSYS GSM 4.3 or to improve the existing functions. A firmware update can be performed with the help of a terminal program that supports ASCII uploads (e.g.
  • Page 85 Try to re set the INSYS GSM 4.3 and to repeat the process from step 5. If this fails and the INSYS GSM 4.3 does no longer react to AT commands, please contact the INSYS MI-...

  • Page 86: Firmware History

    Firmware History Note Function loss due to faulty update! The INSYS GSM 4.3 may loose its function, if it is updated with a wrong firmware or if the transfer of the firmware was faulty. The INSYS GSM 4.3 is based on a different hardware than its predecessor product INSYS GSM 4.2.

  • Page 87: Maintenance, Repair And Troubleshooting

    14.3 Repair Send defect devices with detailed failure description to the source of supply of your device. If you have purchased the device directly from INSYS icom, send the device to: INSYS MICROELECTRONICS GmbH, Waffnergasse 8, 93047 Regensburg. Caution! Short circuits and damage due to improper repairs and modifications as well as opening of products.

  • Page 88: Gsm Service Center Numbers

    GSM Service Center Numbers INSYS GSM 4.3 15 GSM Service Center Numbers The following is an overview of the most important mobile phone providers in Germany, Austria and Switzerland. All information is without guarantee of correct- ness and completeness. The specified numbers may only be valid for certain con- tracts with the mobile phone provider.

  • Page 89: Waste Disposal

    INSYS GSM 4.3 Waste Disposal Waste Disposal 16.1 Repurchasing of Legacy Systems According to the new WEEE guidelines, the repurchasing and recycling of legacy systems for our clients is regulated as follows: Please send those legacy systems to the following address, carriage prepaid:...

  • Page 90: Declaration Of Conformity

    Declaration of Conformity INSYS GSM 4.3 Declaration of Conformity This device complies with the requirements set out in the Council Directive on the Approximation of the Laws of the Member States relating to Electromagnetic Compatibility 2004/108/EC and the Council Directive relating to Low Voltage 2006/95/EC as well as the Council Directive R&TTE 1999/5/EC.

  • Page 91: Tables And Diagrams

    Figure 1: Control elements/displays (INSYS GSM 4.3)..........22 Figure 2 Control elements/displays (INSYS GSM 4.3 compact)......22 Figure 3: Connections on the front panel of the device (INSYS GSM 4.3) ....26 Figure 4: Connections on the front panel of the device (INSYS GSM 4.3 compact)26 Figure 5: Connections on the top of the device ............

  • Page 92: Index

    Index INSYS GSM 4.3 Index Additional information....... 9 Modification ......13, 87 Alternative results ......9 Moisture ........13, 30 AT commands ......... 52 Mounting......... 30 Audio connection ...... 26, 29 Overcurrent ........13 Automatic call acceptance ....56 Overvoltage ........14 Breakdown ........
  • Page 93 INSYS GSM 4.3 Index SIM PUK.......... 41 Terminal program......84 Status LED ........ 23, 24 Transport ......... 11 Status of the PIN request ....41 Update........84, 86 Storage..........11 Usage ..........10 Surface ..........14 Usage according to the regulations 10 Switch cabinet.........
