Operating Principle
11.4.3

Using several profiles

The versatile possible applications of the router suggest the use of several profiles.
The following sections describe the profile handling.
11.4.3.1 Storing a profile
Settings made in the opened profile are stored in this profile with a click on the but-
ton "OK". They will not become effective in the running profile with this. They be-
come only effective if the opened profile is activated, i.e. made the running profile.
11.4.3.2 Activating a profile
A click on the button with the blinking gear symbol
opened profile, i.e. it becomes the running profile.
A stored profile can be activated and opened in the "Administration" menu on the
"Profiles" page by clicking the button with the gear symbol
tive profile.

If the router is still in default settings, a changed profile cannot be
activated until an authentication has been configured.
11.4.3.3 Opening a profile for editing
A stored profile can be opened in the "Administration" menu on the "Profiles" page
by clicking the button with the folder symbol
11.4.3.4 Creating a profile
A new profile can be created from:
• the running profile
• stored profiles
• the default settings
For this, you need to make the correspondent selection in the "Administration"
menu on the "Profiles" page behind "Create profile from". The new profile will be
created with a click on the button "OK" and it appears in the list of profiles.
The profile can then be given a descriptive name. It must first be opened to edit it.
11.4.3.5 Exporting a profile
Profiles stored on the router can be exported to the computer, i.e. downloaded in
the "Administration" menu on the "Profiles" page.
A click on the button for the binary file download
downloads the profile as a binary file. This is recommended to archive the profile or
transmit it to another router, e.g. a backup device.
A click on the button for the ASCII file download
downloads the profile as an ASCII configuration file. This is recommended if the
profile is to be edited manually on the computer.
86
in the title bar activates the
behind the respec-
behind the respective profile.
behind the respective profile
behind the respective profile
MRX
