7.9.2 Connections as well as display and control elements

SFP1
SFP2
Figure 39: MRcard Fiber – connections, display and control elements at the front
LED Colour
green
Power
orange
WAN green
green
yellow
SFP1
red
green
yellow
SFP2
red
Table 40: MRcard Fiber – meaning of the display elements
SFP cage 1
SFP cage 2
Function off
Supply
WAN chain inactive
Slot de-
SFP status
activated
Slot de-
SFP status
activated
blinking
1x for soft reset
3x for resetting to
default settings
establishing
Data transmission
Module detected,
no optical signal
present
Data transmission
Module detected,
no optical signal
present
Technical Information
on
via V+
1
via V+
2
established
Ethernet link es-
tablished
Optical signal
detected, no
Ethernet link
TX failure in
module or miss-
ing module
Ethernet link es-
tablished
Optical signal
detected, no
Ethernet link
TX failure in
module or miss-
ing module
61
