Preface INSYS ADSL 1.0 Preface This manual allows for the safe and efficient use of the product. The manual is part of the product and must always be stored accessible for installation, commission- ing and operating personnel. Defects Liability Terms A usage not according to the intended purpose, an ignorance of this documenta- tion, the use of insufficiently qualified personnel as well as unauthorised modifica- tions exclude the liability of the manufacturer for damages resulting from this.
INSYS ADSL 1.0 Preface Marking of Warnings and Notes 1.2.1 Symbols and Key Words Danger! Risk of severe or fatal injury One of these symbols in conjunction with the key word Danger indicates an imminent danger. It will cause death or severe injuries if not avoided.
Preface INSYS ADSL 1.0 Symbols and the Formatting in this Manual This section describes the definition, formatting and symbols used in this manual. The various symbols are meant to help you read and find the information relevant to you. The following text is structured like a typical operating instruction of this manual.
INSYS ADSL 1.0 Safety Safety The Safety section provides an overview about the safety instructions, which must be observed for the operation of the product. The product is constructed according to the currently valid state-of-the-art technol- ogy and reliable in operation. It has been checked and left the factory in flawless condition concerning safety.
Safety INSYS ADSL 1.0 Permissible Technical Limits The product is only intended for the use within the permissible technical limits specified in the data sheets. The following permissible limits must be observed: The ambient temperature limits must not be fallen below or exceeded.
INSYS ADSL 1.0 Safety Markings on the Product The identification plate of the product is either a print or a label on a face of the product. Amongst other things, it contains the following markings, which are ex- plained in detail here. Observe manual This symbol indicates that the manual of the product contains essential safety instructions that must be followed...
Safety INSYS ADSL 1.0 Safety Instructions for Electrical Installation The electrical connection must only be made by authorised expert personnel ac- cording to the wiring diagrams. The notes to the electrical connection in the manual must be observed. Otherwise, the protection category might be affected. The safe disconnection of circuits, which are hazardous when touched, is only en- sured if the connected devices meet the requirements of VDE T.101 (Basic re- quirements for safe disconnection).
Page 13
INSYS ADSL 1.0 Safety Caution! Overvoltage and voltage peaks from the mains supply! Fire hazard and damage of the product due to overvoltage. Install suitable overvoltage protection. Caution! Damage due to chemicals! Ketones and chlorinated hydrocarbons dissolve the plastic housing and damage the surface of the device. Never let the device come into contact with ketones (e.g.
General Information INSYS ADSL 1.0 General Information This manual describes different versions of the INSYS ADSL 1.0 that only differ regarding the supported ADSL specification. These devices are referred to as INSYS ADSL 1.0 in the manual. The devices are: ...
INSYS ADSL 1.0 Scope of Delivery Scope of Delivery The scope of delivery for the INSYS ADSL 1.0 includes all accessories listed below. Please check if all accessories are included in the box. If a part is missing or damaged, please contact your distributor. ...
Technical Data INSYS ADSL 1.0 Technical Data Physical Features All specified data was measured with nominal input voltage, at full load, and an ambient temperature of 25°C. The limit value tolerances are subject to the usual variations. Physical Feature Value Operating voltage minimum 10 V DC maximum 60 V DC...
INSYS ADSL 1.0 Display and Control Elements Display and Control Elements Figure 1: Display and control elements on the front of the device Position Description Power LED ADSL LED Reset key LAN status LED (yellow) LAN status LED (green) Table 3: Description of the display and control elements on the front panel of the device...
Display and Control Elements INSYS ADSL 1.0 Meaning of the Displays Colour Function flashing blinking missi Power green Supply present setup connected search green SYNC (hand- (show- (training) shake) time) ADSL ADSL traf- yellow WAN Ethernet yellow Traffic traffic status green Link connected...
INSYS ADSL 1.0 Connections Connections Front Panel Connections Figure 2: Connections on the front panel of the device Position Description Ethernet port (RJ45, 10/100 BT) Table 6: Description of the connections on the front panel of the device...
Connections INSYS ADSL 1.0 Connections on the Top Figure 3: Connections on the top of the device Terminal Description Description Reset Reset input Ground 10 ... 60 VDC Power supply 10 V – 60 V DC Ground Table 7: Description of the connections on the top of the device...
INSYS ADSL 1.0 Connections Connections on the Bottom Figure 4: Connections on the bottom of the device Terminal Description Description ADSL Line b ADSL line connection wire b ADSL Line a ADSL line connection wire a – ADSL Line ADSL line connection RJ45 Table 8: Description of the connections on the bottom of the device ADSL Line Connection RJ45 Figure 5: RJ45 connector...
Function Overview INSYS ADSL 1.0 Function Overview The INSYS ADSL 1.0 provides you with the following functions: Additional software watchdog The INSYS ADSL 1.0 also provides a software watchdog for function monitoring in addition to the hardware watchdog. Bridge for PPPoE connections The INSYS ADSL 1.0 can forward PPPoE connections to the DSL provider.
INSYS ADSL 1.0 Mounting Mounting This section describes how to mount the INSYS ADSL 1.0 to a DIN rail, connect the power supply and uninstall it again. Observe the instructions in the "Safety" section of this manual, in particular the "Safety Instructions for Electrical Installation"...
Page 24
Mounting INSYS ADSL 1.0 Mounting the device to the DIN rail How to mount the INSYS ADSL 1.0 to a DIN rail: Position the device at the DIN rail as seen in the following diagram. There are two snap-in hooks at the upper and lower edge of the DIN rail groove of INSYS ADSL 1.0.
Page 25
INSYS ADSL 1.0 Mounting Disconnecting the power supply The device is mounted to the DIN rail. The power supply is connected and switched off. Disconnect the ground lead of the power supply from the terminal "GND". Disconnect the plus pole of the power supply from the terminal for the power supply.
Page 26
Mounting INSYS ADSL 1.0 Turn the Philips screwdriver into the direction of the INSYS ADSL 1.0 as shown in the following figure. The plastic spring of the snap-in hook is stretched. While you hold the plastic spring apart with the lower snap-in hooks, pull the INSYS ADSL 1.0 away from the DIN rail.
INSYS ADSL 1.0 Initial Operation Initial Operation This chapter describes how to activate the INSYS ADSL 1.0, i.e. how to connect the INSYS ADSL 1.0 to a PC, and how to prepare it for the configuration. Connecting the INSYS ADSL 1.0 to a DSL network and a PC How to connect the INSYS ADSL 1.0 to a DSL network and PC for configuration.
Operating Principle INSYS ADSL 1.0 Operating Principle This chapter describes the basic procedures to operate and configure an INSYS ADSL 1.0. In general, the INSYS ADSL 1.0 is configured and operated via a management interface (MI). You can enter these commands with the help of a Telnet connection and the command reference.
INSYS ADSL 1.0 Function Function 12.1 General Functional Description The INSYS ADSL 1.0 tries to achieve the "Showtime" condition automatically, i.e. it tries permanently to synchronise with the DSLAM. The IP address of the INSYS ADSL 1.0 is only required to access the management interface of the INSYS ADSL 1.0.
Function INSYS ADSL 1.0 12.2 Country-Specific Configuration The INSYS ADSL 1.0 is pre-configured for an operation in Germany (VPI: 1, VCI: 32). It may be required to adjust the parameters VPI and VCI to the ISP (Internet Service Provider) for an operation other countries. Please refer to your ISP to obtain the required settings.
INSYS ADSL 1.0 Function 12.3 PPPoA Configuration The INSYS ADSL 1.0 is pre-configured for bridge operation (for PPPoE). For a PPPoA (PPP over ATM) operation, it is necessary to configure the PPPoA connec- tion. Please refer to your ISP to obtain the required settings or access data. Configuration of the PPPoA connection ...
Command Reference INSYS ADSL 1.0 Command Reference The management interface (MI) of the INSYS ADSL 1.0 can be accessed via a Tel- net connection. The management interface provides the commands described in the following for operation and configuration of the INSYS ADSL 1.0. The set value will not be stored permanently and does not become effective right away for modifiable commends.
Page 33
INSYS ADSL 1.0 Command Reference Command Description Display of the bits per bin bitsbin Displays the bits per bin for upload and download. Shortened example: Bits per Bin Upload dslbitsup : 0 16 = 32 = 0 10 11 12 14 14 14 14 15 15 15 15 15 15 15 15 48 = 10 14 15 14 14 14 13 13 12 11 10 Bin 496 = Download...
Page 34
Command Reference INSYS ADSL 1.0 Command Description Display and configuration of the IP address Displays the IP address of the INSYS ADSL 1.0 or configures it. The IP address of the INSYS ADSL 1.0 is displayed by entering ip without any further parameters: IP : <IP address>...
Page 35
INSYS ADSL 1.0 Command Reference Command Description Display and configuration of the DNS server request ppp_dns Displays or configures, whether the INSYS ADSL 1.0 requests the IP address of the DNS server from the remote terminal. The current setting is displayed by entering ppp_dns without any further parame- ters (default = 1): PPP DNS usage: <x>...
Page 36
Command Reference INSYS ADSL 1.0 Command Description Display of the condition of the PPPoA connection ppp_info Displays the condition of the PPPoA connection. By entering ppp_info the condition of the PPPoA connection is displayed includ- ing important parameters: Connected since: <Data and time> PPP IP address local: <local IP address>...
Page 37
INSYS ADSL 1.0 Command Reference Command Description Display of the signal information signal Displays the signal information of the DSL connection of the INSYS ADSL 1.0. Example: Signal Noise Ratio Margin in CPE: 6.65 dB Line attenuation downstream: 0.0 dB Line attenuation upstream: 2.0 dB Transmit power downstream:...
Page 38
Command Reference INSYS ADSL 1.0 Command Description Display of synchronisation state state Displays the synchronisation state of the INSYS ADSL 1.0. Response: The INSYS ADSL 1.0 tries to connect to the DSLAM state : Handshake The INSYS ADSL 1.0 is currently connecting to the state : Training DSLAM The INSYS ADSL 1.0 is connected to the DSLAM (SYNC)
Page 39
INSYS ADSL 1.0 Command Reference Command Description Display and configuration of the Virtual Port Identifier (VPI) Displays the VPI of the INSYS ADSL 1.0 or configures it. The VPI of the INSYS ADSL 1.0 is displayed by entering vpi without any further parameters (0-256;...
14.3 Repair Send defect devices with detailed failure description to the source of supply of your device. If you have purchased the device directly from INSYS icom, send the device to: INSYS MICROELECTRONICS GmbH, Hermann-Köhl-Str. 22, 93049 Regensburg. Caution! Short circuits and damage due to improper repairs and modifications as well as opening of products.
INSYS ADSL 1.0 Waste Disposal Waste Disposal 15.1 Repurchasing of Legacy Systems According to the new WEEE guidelines, the repurchasing and recycling of legacy systems for our clients is regulated as follows: Please send those legacy systems to the following address, carriage prepaid: Frankenberg-Metalle Gaertnersleite 8 D-96450 Coburg...
Declaration of Conformity INSYS ADSL 1.0 Declaration of Conformity This device complies with the requirements set out in the Council Directive on the Approximation of the Laws of the Member States relating to Electromagnetic Compatibility 2004/108/EC and the Council Directive relating to Low Voltage 2006/95/EC as well as the Council Directive R&TTE 1999/5/EC.
INSYS ADSL 1.0 Tables and Diagrams Tables and Diagrams 17.1 List of Tables Table 1: Physical Features ..................16 Table 2: Technological Features................16 Table 3: Description of the display and control elements on the front panel of the device ........................17 Table 4: Meaning of the LED displays..............
Index INSYS ADSL 1.0 Index Accessories ........15 Liquids........12, 23 Additional information....... 8 Management interface ....29, 32 ADSL LED ......... 17, 18 Marking ..........7 Alternative results ......8 MI port ..........34 Annex ..........32 Modem state ........38 Bits per bin ........
Page 45
INSYS ADSL 1.0 Index Responsibilities of the operator..10 Synchronisation state...... 38 Safety ..........9 System information ......33 Scope of Delivery ......15 Technological Features ....16 Short-cut ........12, 40 Telnet ..........28 Signal information ......37 Telnet connection...... 28, 32 software restart .......
