Connectors

S/PDIF Coax Connectors (J7 and J8)

Part Description
Coaxial
Two-channel RCA interconnect
cable

DPI Header (P3)

The DPI connector (
from of a .1" spacing header. When using the header to access the DPI
pins of the processor, ensure that signals, which normally drive the DPI
pins, are disabled. For more information, see
Part Description
20-pin IDC header

DAI Header (P4)

The DAI connector (
from of a .1" spacing header. When using the header to access the DAI
pins of the processor, ensure that signals, which normally drive the DAI
pins, are disabled. Refer to
more information on how to disable signals already being driven from
elsewhere on the EZ-KIT Lite.
Part Description
26-pin IDC header
2-24
Manufacturer
SWITCHCRAFT
Mating Cable
MONSTER CABLE
) provides access to all of the DPI signals in the
P3
Manufacturer
FCI
) provides access to all of the DAI signals in the
P4
"Codec Setup Switch (SW3)" on page 2-11
Manufacturer
BERG
ADSP-21375 EZ-KIT Lite Evaluation System Manual
Part Number
PJRAN1X1U01
BI100-1M
"DPI Interface" on page
Part Number
68737-420HLF
Part Number
4102-T08-13LF
2-5.
for
