Installation and Session Startup
For correct operation, install the software and hardware in the
order presented in the VisualDSP++ Installation Quick Reference
Card.
1. Verify that the yellow USB monitor LED (
USB connector) is lit. This signifies that the board is communicat-
ing properly with the host PC and is ready to run VisualDSP++.
2. From the Start menu, navigate to the VisualDSP++ environment
via the Programs menu.
If you are running VisualDSP++ for the first time, the New Session
dialog box appears on the screen (skip the rest of the procedure and
go to step 3).
If you have run VisualDSP++ previously, the last opened session
appears on the screen.
To switch to another session, via the Session List dialog box, hold
down the Ctrl key while starting VisualDSP++ (go to step 5).
3. In Debug target, select Blackfin Emulators/EZ-KIT Lites.
In Platform, select the appropriate EZ-KIT Lite via a debug agent
(ADSP-BF561 EZ-KIT Lite via Debug Agent).
In Session name, type a new name or accept the default.
4. Click OK to return to the Session List.
5. Highlight the session and click Activate.
ADSP-BF561 EZ-KIT Lite Evaluation System Manual
Using EZ-KIT Lite
, located near the
LED4
1-5
