Frequency
Description
Frequency Span
Standard instrument
Option B25
Resolution Bandwidth
(Spectrum Measurement)
Range
Overall
Span = 1 MHz
Span = 10 kHz
Span = 100 Hz
Window Shapes
Analysis Bandwidth (Span)
(Waveform Measurement)
Standard instrument
Option B25
Specifications
10 Hz to 10 MHz
10 Hz to 25 MHz
100 mHz to 3 MHz
50 Hz to 1 MHz
1 Hz to 10 kHz
100 mHz to 100 Hz
Flat Top, Uniform, Hanning, Hamming,
Gaussian, Blackman, Blackman-Harris,
Kaiser Bessel (K-B 70 dB, K-B 90 dB &
K-B 110 dB)
10 Hz to 10 MHz
10 Hz to 25 MHz
Supplemental
Information
51
