Amplitude Mod ulation
Description
Post-Demod Distortion Residual
b
Distortion (SINAD)
THD
Post-Demod Distortion Accuracy
(Depth: 5 to 90
Rate: 1 to 10 kHz)
b
Distortion (SINAD)
THD
Distortion Measurement Range
b
Distortion (SINAD)
THD
c
FM Rejection
d
Residual AM
a. Channel BW is set to 15 times of Rate (Rate 50 kHz) or 10 times the Rate (50 kHz < Rate 100 kHz).
b. SINAD [dB] can be derived by 20  log10(1/Distortion).
c.
FM rejection describes the instrument's AM reading for an input that is strongly FMed (and no AM); this specifi-
cation includes contributions from residual AM
d.
Residual AM describes the instrument's AM reading for an input that has no AM and no FM; this specification
includes contributions from AM depth accuracy.
Specifications
a
Supplemental Information
0.3 (nominal)
0.16 (nominal)
1  Reading  DistResidual) (nominal)
1  Reading  DistResidual) (nominal)
Residual to 100(nominal)
Residual to 100(nominal)
0.5(nominal)
0.2 (nominal)
