Vector Signal Analysis Performance (N9064A-1FP)
Frequency
Description
Range
Center Frequency Tuning
Resolution
Frequency Span
Frequency Points per Span
Resolution Bandwidth (RBW)
Description Specs & Nominals
Range RBWs range from less than 1 Hz
to greater than 2.8 MHz (standard), or
greater than 7 MHz (Option B25)
RBW
Shape Factor
Window Selectivity
Flat Top 0.41
Gaussian Top 0.25
Hanning 0.11
Uniform 0.0014
94
Specs & Nominals
1 mHz
10 MHz (standard)
Calibrated points: 51 to 409,601
Displayed points: 51 to 524,288
Passband
Flatness Rejection
0.01 dB > 95 dBc
0.68 dB > 125 dBc
1.5 dB > 31 dBc
4.0 dB > 13 dBc
Supplemental Information
See "Frequency Range" on page 12
wider with options, such as 25 MHz
(Option B25)
Supplemental Information
The range of available RBW choices is a function of
the selected frequency span and the number of
calculated frequency points. Users may step through
the available range in a 1-3-10 sequence or directly
enter an arbitrarily chosen bandwidth.
The window choices below allow the user to
optimize the RBW shape as needed for best
amplitude accuracy, best dynamic range, or best
response to transient signal characteristics.
