Studio Mode - ETC Source Four LED 3 Series User Manual

Studio Mode

1. Press the Function button (
then press the Intensity encoder to select it.
DMX
Int
CCT
Tint
Tune
3200K
Press an encoder to play that
studio preset...
2. Press the color encoder that matches the studio preset you want to use (Blue = 3200 K,
Green= 4500 K, Red= 5600 K).
More Options
Turn off the preset: Press the Intensity encoder to toggle the intensity value from the
•
current value to 0. Press the Intensity encoder again to toggle back to the previous
intensity value.
Modify the preset: Turn the encoders to change the corresponding values. For example,
•
turn the Intensity encoder to change the intensity value, or turn the blue encoder to
change the color temperature value.
Modify the intensity: Turn the Intensity encoder to adjust the
•
intensity, or press and turn the Intensity encoder to adjust the
intensity by 1/4 stop.
Modify the tuning: Press and turn the red encoder to change
•
the value to Metamer, and then turn the red encoder to
change the Tune value (the "recipe" of the metamer). Press
and turn the red encoder again to return to the Brightest or Spectral options. For more
information on the three methods, see
Revert to the original preset: Press the encoder that corresponds to the preset again to
•
restore the original values.
Save the modified preset: Press and hold the encoder that corresponds to the preset that
•
you want to re-record. The display shows a three-second countdown before re-recording
the preset.
Note:
DMX mode is set to Studio. See
Use Fixture in Stand-alone Mode
Studio
100%
3200 K
0.0 Green
Brightest
4500K 5600K
The CCT, Tint, and Tune values match the values that are available when the
), use the Intensity encoder to navigate to Studio Mode, and
DMX
Int
CCT
Tint
Tune
3200K
...or turn an encoder to modify the
value in the matching field.
Tuning (Color calculation method)
DMX Control Channels on
Turn to adjust intensity, press to toggle
between current intensity and 0, or
press and turn to adjust by 1/4 stop.
Studio
100%
3125 K
0.0 Green
Brightest
4500K 5600K
Int + 1/4 Stop
Tune 0.3 Metamer
.
page 13.
