Parameter
Tuning
(Color
calculation
method)

Set DMX Loss Behavior

In the DMX screen, turn the red encoder to set the DMX loss behavior. Options are:
Instant:The fixture immediately goes dark.
•
HLL 2min: Hold last look for two minutes or until you make local changes. If you make no
•
changes during the two minutes, the fixture fades out over two seconds.
HLL: Hold last look until you make local changes. This is the default setting.
•
Preset 12: Two-second fade from last look to Preset 12.
•
Use Fixture in DMX Mode
DMX Value Description
0–49 Brightest
50–149
Spectral
150–170 Expanded mode: Reserved
Studio mode: Metamer
(linear adjustment from
-1 to 1)
171–255 Reserved
Comments
Calculation uses a combination of LEDs to produce the
brightest version of the selected chromaticity.
Calculation uses a combination of LEDs to produce the
best spectral match of the selected chromaticity. The
Spectral option results in higher color rendering, but
lower intensity levels.
This range is reserved for future development, but
currently outputs the Brightest color calculation
method.
Manually tune the metamer using the Spectral
calculation method.
This range is reserved for future development, but
currently outputs the Brightest color calculation
method.
