Store the Antenna

When transporting or storing the fixture, store the wireless antenna
on the yoke to protect it .
1. Grasp the antenna on the ribbed section at the base and
unscrew it from the fixture.
2. Insert the base of the antenna into the antenna storage
accessory, and then snap the top of the antenna into the
accessory clip.

Clean the Lens and the Fixture Housing

Clean the lens and the heat-dissipating fins on the fixture housing at least once a year to ensure
optimum performance. You may need to clean more often, depending on the type of fixture use
and amount of fixture use.
WARNING:
Allow fixture to cool completely before you clean.
•
Disconnect all power and DMX cables before you clean.
•
Do not spray liquids into the fixture.
•
1. Remove the shutter barrel and lens tube (A) by removing the screw (B) and the barrel
rotation knob (C), and then separate the fixture and shutter barrel.
2. Use a clean micro-fiber cloth to clean the lens. You can use isopropyl alcohol on the cloth.
However, do not spray the cleaning solution directly onto the lens or the interior of the
fixture.
3. Reinstall the shutter barrel and lens tube, and secure with the retaining bolt and the barrel
rotation knob.
4. Clean the four sets of heat-dissipating fins on the fixture enclosure (D) using a soft cloth or
compressed air.
Note:
see the XDLT Lens Tubes Assembly Guide, which you can download at etcconnect.com.
28
Note the following safety warnings before cleaning:
A
For information on disassembling and cleaning XDLT lens tube components,
B
C
Source Four LED Series 3 User Manual
Insert base,
then snap into
accessory clip
D
