Preset Mode

1. Press the Function button (
then press the Intensity encoder to select it.
The background approximates
the preset color.
DMX
Int
Preset
Fade
Press to
play/pause
the preset.
2. Turn the green encoder to select a preset, and then press the encoder to play the preset.
Number
1
2
3
4
5
6
More Options
Pause the preset fade: Press the green encoder to toggle between play and pause.
•
Stop the preset: Press the red encoder.
•
Modify the preset: Turn the Intensity encoder to change the intensity, or turn the red
•
encoder to change the fade value.
Capture the current DMX look: Press and hold the blue encoder (for the Snapshot icon
•
The display shows a 3-second countdown before re-recording the preset. Capture is
limited to three DMX modes: 3 Ch RGB, Studio, and Expanded.
Modify the preset color: Press the blue encoder (for the Edit icon
•
Color screen, turn the encoders to change the corresponding values. The crosshairs on the
display indicate the approximate color. Press the green encoder (for the Save icon
save the new color to the preset.
Push the preset to connected fixtures: Press the Menu button (
•
Intensity encoder to navigate through the menu: Local Settings > Push Presets. When the
screen prompts you to confirm, press the green encoder (for the OK icon
20
), use the Intensity encoder to navigate to Preset Mode, and
Turn an encoder to modify the
value in the matching field.
Preset
100%
4 Yellow
3 seconds
Press to Press to modify the
stop the preset color, or hold
preset. to capture DMX.
Preset
3200 K
4500 K
5600 K
Yellow
Dark Straw
Red
Edit Preset Color 4
100%
H: 39 S: 215 I: 100%
Press to
save the
new color.
Number Preset
7 Medium Pink
8 Magenta
9 Medium Blue
10 Primary Blue
11 Blue Green
12 Green
). In the Edit Preset
), and then use the
Source Four LED Series 3 User Manual
Press to return
to the Preset
screen.
).
) to
) to continue.
