Overview

Fixture

C
B
A
Yoke tilt-lock: Tilt the fixture as needed, and then turn the tilt-lock clockwise to lock the
A
position. If necessary, pull the tilt-lock away from the stem to adjust the tilt-lock position.
B Safety cable attachment point: Attach safety cable to the fixture housing.
Antenna storage accessory: When transporting or storing the fixture, store the wireless
C
antenna on the yoke to protect it (
D Barrel rotation knob: Loosen to rotate the barrel, and then tighten to secure it (
E Shutters: Use four framing shutters to shape the beam.
Pattern holder slot and accessory slot: Insert an A-size, B-size, or glass pattern holder, and
F
insert an accessory, such as a drop-in iris or motorized pattern device (
Beam focus knob: Loosen to adjust the lens tube position, and then tighten to secure it
G
( ).
page 10
H Accessory holder: Insert a color frame or other accessory, and then lock the holder.
Power In and Power Thru connectors: powerCON
I
power thru (
page 9
J DMX In and DMX Thru connectors: Five-pin XLR connectors for DMX/RDM in and thru.
User interface: View the fixture status, set the DMX address and mode, or set stand-alone
K
options.
Antenna: For use when controlling the fixture using wireless DMX (
L with the antenna stored in the antenna storage accessory (C). Install before using the fixture
( ).
page 7
NFC (Near Field Communication) tag: Use the Set Light app to wirelessly configure the fixture,
M
with or without power applied to the fixture (
Overview
E
F
D
E
page 28
).
Source Four LED Series 3,
shown with 26° XDLT lens tube
H
G
).
®
TRUE1 TOP connectors for power in and
).
page 21
I
J
K
L
).
page 11
).
page 11
). The fixture ships
page 21
I
J
M
5
