Specifications and Reference

For current and complete compliance and specifications, see the Source Four LED Series 3
datasheet at etcconnect.com.

Environment

The Source Four LED Series 3 operates in ambient temperatures of 0°C–40°C (32°F–104°F) and
is rated IP20 (for use in dry locations only).
Fixture temperature information:
Maximum recommended ambient operating temperature: Ta=40°C (104°F)
•
Maximum anticipated external surface temperature: Tmax=80°C (176°F)
•
External temperature after 5 minutes of full-brightness operation at 25°C (77°F) ambient:
•
40°C (104°F)
External Temperature (steady state achieved) at 25°C (77°F): 51°C (124°F)
•

Weight

Component
Fixture body
Shutter barrel
Fixture body and shutter barrel

Electrical

Operates between 100 VAC and 240 VAC at a frequency of 50/60 Hz.
•
Maximum power consumption is 375 W
•
Up to 4 fixtures (16 A max) may be linked via power thru connector (5 luminaires total per
•
circuit) when used with an R20 Relay Module, ER15 Relay Module, or Unison Echo Relay
Panel. Consult breaker trip curves when used with other equipment. Requires power from
a non-dimmable source.
Inrush:
•
120 V: 40 A
-
230 V: 80 A
-
Typical Power Consumption
Lustr X8
Daylight HDR
Specifications and Reference
Idle Power/Current
Direct at Full/Current
Idle Power/Current
Direct at Full/Current
100 V
6 W 0.10 A 6.3 W
310 W 3.15 A 307 W
6 W 0.10 A 6.3 W
345 W 3.45 A 340 W
kg
6.76
2.11
8.87
120 V 230 V
0.09 A 4.7 W
2.6 A 305 W
0.09 A 4.7 W
2.85 A 330 W
lb
14.90
4.65
19.55
0.06 A
1.35 A
0.06 A
1.5 A
