ETC Source Four LED 3 Series User Manual page 18

Parameter
Curve
Fan
Mix
Strobe
Tint
14
DMX Value Description
0–9 Incandescent
10–19 Linear
20–29 Incandescent Red Shift
30–39 Linear Red Shift
40–255 Reserved
0–9 Auto
10–19 Off
20 Slow
21–248 Linear Increase in Speed
249 Fast
250–255 Auto
0 Full Studio
1–254 Linear interpolation from
Studio to RGB
255 Full RGB
0 No Strobe
1–40 Dark Strobe
41–80 Bright Strobe
81–120 Pulse Strobe
121–160 Random Strobe
161–200 Flicker Effect
201–240 No Strobe
241–254 LEDs Off
255 No Strobe
0 Neutral
1–127 Linear between +10 and 0
128 Neutral
129–255 Linear between 0 and -10
Comments
In Direct Mode, the fixture uses Incandescent instead of
Incandescent Red Shift.
In Direct Mode, the fixture uses Linear instead of Linear
Red Shift.
All modes use Incandescent in the range of DMX values
for Reserved.
When the fixture gets too hot, the fixture reduces the
intensity instead of turning on the fan.
Minimum fan speed. When the fixture gets too hot, the
fixture reduces the intensity instead of adjusting the
fan.
When the fixture gets too hot, the fixture reduces the
intensity instead of adjusting the fan.
Maximum fan speed (100%). When the fixture gets too
hot, the fixture reduces the intensity instead of
adjusting the fan.
Shutter open
Range is 1–40 Hz.
Range is 1–40 Hz.
Strobe includes a fade up and fade down on each pulse.
Strobe pulses at random intervals.
Strobe pulses at random intervals and at random
intensity levels.
Shutter open
Shutter closed
Shutter open
Tint shifts toward green (+10) as the DMX value
decreases to 1.
Tint shifts toward magenta (-10) as the DMX value
increases to 255.
Source Four LED Series 3 User Manual
