LED display
The meaning of LED indications are as shown in the table below.
Items
POWER
COMMUNICATION
The range of the LED pressure display is different according to the pressure range and the unit of
the display.
unit
MPa
2
Kgf/cm
bar
PSI
kPa
(note1)：The mark "｡" is blinking the decimal point, and it is shown a minus.
(note2)：When the digit overflows, the following of "9" are substituted by "A".
(example: The following of 999(kPa) are displayed as A00(kPa), and it shows 1000
kPa.)
(note3)：When the display exceeds the lower bound value, "
(note4)：When the display exceeds the upper bound value, "
Maintenance
■
Before performing maintenance, turn off the power supply, stop the air supply, exhaust the residual
compressed air in the piping, and verify the release of air.
■ Foreign matter caught in the inlet or exhaust piping may interfere with normal operation.
Periodic cleaning is necessary.
■ Do not use solvents such as benzene, thinner, etc., to clean the product including the switch
cover. Use a soft dry cloth to remove stains.
Refer to the SMC website
(URL http://www.smcworld.com) for more information
about troubleshooting.
This operation manual refers to all standard types
and is partially applicable to special models.
4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN
Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362
URL http://www.smcworld.com
NOTE: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer.
© 2021 SMC Corporation All Rights Reserved
ON
Normal
(normal operation)
IO-Link
communication is
not established
(SIO mode)
ITV*01*
｡020 to .120
0｡20 to .120
0｡20 to .120
3｡0 to 18.0
-20 to 120
Flashing
Communication
system error
IO-Link
communication is
established
ITV*03*
｡100 to 600
1｡00 to 6.00
1｡00 to 6.00
14｡0 to 84.0
-100 to 600
- 31 -
OFF
Communication
EEPROM error
/ Stop the power supply.
Stop the power supply.
ITV*05*
｡180 to .A80
1｡80 to A.80
1｡80 to A.80
-26 to 156
-180 to A80
" is displayed.
" is displayed.
Revision history
ITV209*
-
-
-
-
16 to -96
