SMC Networks ITV10*0-PR*-Q Series Installation And Maintenance Manual

ITV2-PR-TFM132
Installation and Maintenance Manual
Electro-Pneumatic Regulator
(for PROFIBUS DP)
ITV10*0-PR****-Q,
ITV20*0-PR****-Q,
ITV30*0-PR****-Q
1 Safety Instructions
This manual contains essential information for the protection of users and
others from possible injury and/or equipment damage.
• Read this manual before using the product, to ensure correct handling,
and read the manuals of related apparatus before use.
• Keep this manual in a safe place for future reference.
• These instructions indicate the level of potential hazard by label of
"Caution", "Warning" or "Danger", followed by important safety
information which must be carefully followed.
• To ensure safety of personnel and equipment the safety instructions in
this manual and the product catalogue must be observed, along with
other relevant safety practices.
Indicates a hazard with a low level of risk, which if
Caution not avoided, could result in minor or moderate
injury.
Indicates a hazard with a medium level of risk,
Warning
which if not avoided, could result in death or
serious injury.
Indicates a hazard with a high level of risk, which if
Danger
not avoided, will result in death or serious injury.
• Electromagnetic compatibility:
This product is class A equipment intended for use in an industrial
environment. There may be potential difficulties in
electromagnetic compatibility in other environments due to conducted as
well as radiated disturbances.
• The compatibility of pneumatic equipment is the responsibility of
the person who designs the pneumatic system or decides its
specifications.
Since the products specified here can be used in various operating
conditions, their compatibility with the specific pneumatic system must
be based on specifications or after analysis and/or tests to meet specific
requirements.
• Only trained personnel should operate pneumatically operated
machinery and equipment.
Compressed air can be dangerous if an operator is unfamiliar with it.
Assembly, handling or repair of pneumatic systems should be performed
by trained and experienced personnel.
• Do not service machinery/equipment or attempt to remove
components until safety is confirmed.
• Inspection and maintenance of machinery/equipment should only be
performed after confirmation of safe locked-out control positions.
• When equipment is to be removed, confirm the safety process as
mentioned above. Switch off air and electrical supplies and exhaust all
residual compressed air in the system.
• Before machinery/equipment is re-started, ensure all safety measures
to prevent sudden movement of cylinders etc. (Supply air into the
system gradually to create back pressure, i.e. incorporate a soft-start
valve).
• Do not use this product outside of the specifications. Contact SMC
if it is to be used in any of the following conditions:
• Conditions and environments beyond the given specifications, or if the
product is to be used outdoors.
• Installations in conjunction with atomic energy, railway, air navigation,
vehicles, medical equipment, food and beverage, recreation equipment,
emergency stop circuits, press applications, or safety equipment.
• An application, which has the possibility of having negative effects on
people, property, or animals, requiring special safety analysis.
• Ensure that the air supply system is filtered to 5 microns.
2 Specifications
Model ITV*010 ITV*030
Min.supply pressure (Set pressure) + 0.1 MPa
Max.supply pressure 0.2 MPa 1.0 MPa
0.005 ~ 0.005 ~
Set pressure range
0.1 MPa 0.5 MPa
Supply voltage 24 VDC±10%
Current consumption Max. 160 mA
Input/output data 12bit/12bit (data 4095 corresponds to 100%F.S.)
Linearity Max. ±1%F.S.
Hysteresis Max. 0.5%F.S.
Repeatability Max. ±0.5%F.S.
Sensitivity Max. 0.2%F.S.
Temperature characteristics
Max. ±0.12%F.S./°C
Operating temperature 0~50°C (without condensation)
Protection structure
Model ITV10*0 ITV20*0
Size (mm) 50×50×124 50×50×146
Weight (No option) 350 g
Table 1.
3 Operation Principle
When the input signal increases the supply solenoid valve
the exhaust solenoid valve turns off. Supply pressure is passed to the
pilot valve through the supply solenoid valve. The pilot valve will open
the main valve allowing partial supply pressure to pass to the out port. The
pressure sensor will provide output pressure feedback to the control
circuit . The control circuit will balance the input signal and output
pressure to ensure that the output pressure remains proportional to the
ensuring
input signal.
Supply pressure
+ Supply solenoid valve
Input
Control circuit
signal
– Exhaust solenoid valve
Pressure sensor
Fig. 1 - Control diagram
LED
indicator
Power supply
Control
circuit
Input signal
Supply solenoid
valve
EXH
SUP
Pilot valve
Fig. 2 - Schematic diagram
4 Wiring
ITV*050 ITV2090
(Set pressure) Connect the cable to the connector on the main unit as shown in the
–13.3 kPa following diagram. Take precautions, as incorrect wiring will damage the
unit. Use a DC power supply capable of supplying the necessary power
1.0 MPa -101 kPa
requirements with minimal ripple. When 3 m straight cable connection is
0.005 ~
-1.3 ~ -80 kPa
specified, this refers to the power supply cable, the communications cable
0.9 MPa
should be ordered separately.
Item
Connector for
power supply
3
Connector for 2 5 4
communication
1
IP65
ITV30*0
Note: Wire colour when the optional cable is used.
66×66×167
450 g 750 g
5 LED Display and Communication Protocol
• LED Display
Communication line
RUN LED
turns on and
DIA LED
SUP
ITEM LED ON
RUN Power ON (Green)
DIA Diagnostic error (Red)
BF Profibus communication error (Red)
OUT
• Communication Protocol
Pilot valve
Item Specification
Communication PROFIBUS DP
protocol
(Note)
Baud rate 9.6 k/ 19.2 k/ 45.45 k/
93.75 k/ 187.5 k/ 500 k/ 1.5 M/
3 M/ 6 M/ 12 Mbps
GSD-File SMC_1412.GSD
Occupied area 1 word / 1 word
(Input/output data)
Communication 12 bit (4096 resolution)
data resolution
Address setting Switch setting /
Software setting
Terminator Built into the product
Exhaust solenoid
valve Note: Baud rate relates to communication distance
Pilot EXH
6 Switch Setting
Pressure
sensor
• Selection of address setting mode
Node address of the product can be set by
OUT
software mode (SW) or hardware mode (HW).
When software mode is selected, the
communication master sets the node address.
Setting range is 1 to 125.
• Address set switch
In hardware mode use the switches
shown, to set the node address.
• Address setting range is 01 to 99.
6 Switch Setting (continued)
• Setting the terminator
Set Profibus communication line terminator.
(Note)
Pin assignment Wire colour
1. +24 V Brown
When the product is connected to the Profibus communication line,
2. N.C. –
ensure the switch is set to "with terminator".
3. GND Blue
4. N.C. –
1. N.C. –
• Setting the address switch requires the removal of 4 screws in the front
2. RXD/TXD_N(A) Green
3. N.C. – panel of the unit (Fig 3). Take care as the panel hinges to a maximum of
4. RXD/TXD_P(B) Red 90 degrees.
• After setting an address, always close and fix the panel securely.
5. N.C. –
Table 2.
Tighten the screws to torque of 0.6 – 0.8 N•m
Power supply line
BF LED
Address switch
OUT
Fig. 3 – Features of the ITV.
LED OFF 7 Communication Data Allocation
Power OFF
Internal operation is normal
Profibus communication is normal
Target value
Table 3. (O area)
Remark
For DP-V0
Output pressure
(I area)
Set by master
Lower 2 bits of 7 bytes of
diagnostic area are for diagnostic
Diagnostic (DIA)
information.
Switching by switch
Switching by switch Note: Although 100 %F.S. for target value is 12 bit, communication is
Table 4. available upto 150 %F.S. (accuracy is guaranteed upto 100 %F.S.)
Over range error is output when 150 %F.S. is exceeded.
Output pressure at this time is controlled by the input data immediately
before the error occurred.
Pressure can be set by sending the input data, in which F.S. consists of
12 bits, to the E/P regulator through the master PLC (target value to
word area).
N
O
Setting data
HW/SW
Output pressure
0 0
9 1 9 1
8 2 8 2
7 3 7 3
6 6
4 4
5 5
x10 x1
With terminator Without Without
(factory setting) terminator terminator
Set target value
Resolution: 12 bit (100 %F.S.), Occupied byte: 2 Byte
0 0 0 * Target value (lower 12 bits)
b15 b11 b0
(Note)
Put 0 in upper 4 bits
Monitor the output pressure
Resolution: 12 bit (100 %F.S.), Occupied byte: 2 Byte
0 0 0 * Output pressure (lower 12 bits)
b15 b11 b0
Resolution may exceed 12bit depending on control conditions.
Monitors the product error.
7 bytes are occupied for external diagnostic data.
Diagnostic data allocated to byte 7, as shown below.
Byte7
0 0 0 0 0 0 B A
b7 b0
A. Internal diagnostic error 0: Normal 1: Error
B. Over range error 0: Normal 1: Error
0000h 0FFFh [(a/F.S.) x 4095]
HEX
0 % x F.S. (=0) 100 % x F.S. a
