Zero clear
This function is the same as the function via IO-Link.
The display can be set to zero again by executing "zero clear".
When "zero clear" is executed with residual pressure in the secondary piping, the pressure is
assumed to be zero. Please execute the operation of "zero clear" with the supply pressure is
intercepted, and the piping of the second side removed.
No
(1) Deactivate the key lock if necessary (see page 22).
(2) Press S-key for 2 seconds or more, then go to detail setting mode.
(3) To "F03" by using the △ and ▽ keys.
(4) Press S-key.
Press △ and ▽ keys for 3 seconds or more.
(5)
(press S-key to (3))
"Zero clear" is executed, after 3 seconds.
(6)
(Release keys till less than 3 seconds to (4))
Returns to the state immediately after turning on of the power supply.
(7)
Activate the key lock if necessary (see page 22).
(note)：The adjustable range is within ±5%F.S from the state of the factory shipment. When more
than this range,
Key operation
is displayed and zero-clear is not executed.
(displayed alternately)
second.
- 29 -
LED Display
⇔
flashes on the display
is displayed
is displayed for approx. 1
