Reset function
Clears the minimum and maximum pressure settings. This function is the same as the function
via IO-Link.
Operation
Key operation
No
(1) Deactivate the key lock if necessary (see page 22).
Press the △ and ▽ keys simultaneously
(2)
for 3 seconds or more.
(3)
The settings are reset and returned to the condition before power was supplied.
(4)
Activate the key lock if necessary (see page 22).
Reset content
Item
F_1
F_2
*(Note): Gain (GL） and sensitivity (SL) are not reset.
(current) pressure is displayed
Reset content
0%F.S.
100%F.S.
- 24 -
LED Display
is displayed for approx. 1 second
