Sensitivity setting
Interlocked with the IO-Link parameter.
Normal operation does not require the adjustment of sensitivity.
When the sensitivity is changed, the correction operation of pressure changes.
When the sensitivity is changed to sharp, the hunting of pressure might be occurred. And, when
the sensitivity is changed to dull, there is a possibility that staggering of gradual pressure occur,
because the pressure correction become lower.
No
(1) Deactivate the key lock if necessary (see page 22).
(2) Press S-key for 2 seconds or more, then go to detail setting mode.
(3) To "F02" by using the △ and ▽ keys.
(4) Press S-key.
Set the SENSITIVITY by using the △
(5)
and ▽ keys.
(6) Press S-key.
Press S-key for 2 seconds or more, then go out from detail setting mode.
(7)
(Select the menu with △ or ▽ keys, then jump to another item.)
(8) Activate the key lock if necessary (see page 22).
Relation between setting and sensitivity
Sensitivity Sharp
Setting of
sensitivity
*Default:
Key operation
⇔
(blink and change the rightest digit)
⇔
- 28 -
LED Display
(displayed alternately)
(displayed alternately)
Dull
