Setting using buttons
① If the incorrect key is pressed or incorrect information is displayed during setting, power
must be shut off and the procedure started again.
② It is recommended that the settings are changed without supply pressure. The product
operates immediately maximum and minimum pressures are set and the S-key is pressed.
③ It is recommended that the minimum pressure is output when air is supplied to the inlet,
even if the input signal has not been entered.
④ Output pressure from this product and state of operation are changed by changing of each
setting and function. Each setting and function should be operated by trained and
experienced operator.
⑤
Do not configure settings using the button operation and IO-Link communication at the
same time.If settings are made by both methods, unintended settings may be configured.
Flow of the setting
POWER ON
UNLOCK KEYS
SETTING OF MIN. PRESS.
SETTING OF MAX. PRESS.
(Note 1): Please refer to each contents about operation method.
!
REFER TO P22
* Only when the key lock is active
REFER TO P23 REFER TO P26~29
DETAIL SETTING
Caution
REFER TO P24
RESET
GAIN
SENSITIVITY
ZERO
ZERO CLEAR
INITIALIZE
- 21 -
REFER TO P22
LOCK KEYS
