Doc. No. ITV2-OM00114-B
P R O D U C T
N A M E
E/P Regulator
(CC-Link type)
MODEL/ Series/ Product Number
ITV1000/2000/3000/2090-CC* Series
● Install and operate the product only after reading the Operation Manual carefully and
understanding its contents.
● Specifically, read the safety instructions carefully.
● Keep this operation manual available whenever necessary.
Advertisement
Table of Contents
Related Manuals for SMC Networks ITV1000-CC Series
Summary of Contents for SMC Networks ITV1000-CC Series
- Page 1 Doc. No. ITV2-OM00114-B P R O D U C T N A M E E/P Regulator (CC-Link type) MODEL/ Series/ Product Number ITV1000/2000/3000/2090-CC* Series ● Install and operate the product only after reading the Operation Manual carefully and understanding its contents. ●...
-
Page 2: Table Of Contents
Contents Contents Safety Instructions Handling precautions Wiring method and LED indication System configuration Communication specification Setting of dipswitch Pressure setting and output monitoring Communication data allocation Maintenance and inspection - 1 -... -
Page 3: Safety Instructions P2
E/P Regulator Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) and other safety regulations. - Page 4 E/P Regulator Safety Instructions Caution 1. The product is provided for use in manufacturing industries. The product herein described is basically provided for peaceful use in manufacturing industries. If considering using the product in other industries, consult SMC beforehand and exchange specifications or a contract if necessary.
-
Page 5: Handling Precautions P4
Handling precautions △ Caution ！ If the power supply to this product is turned off due to a power failure during normal operation, the output on the secondary side will be held and air will flow continuously. If supply pressure to this product is interrupted or shut off, while the power is still on, the internal solenoid valve will continue to operate and a humming noise will be... - Page 6 △ Caution ！ Take following steps avoid malfunction due to noise. 1. Install a line filter etc. to the AC power line to reduce / eliminate power supply noise. 2. Avoid malfunction due to noise by installing this product and its wiring away from strong electric fields, such as those of motors and power cables, etc.
-
Page 7: Wiring Method And Led Indication P6
Wiring method and LED indication △ CAUTION ！ ① Proceed carefully, as incorrect wiring can cause damage. ② Use a DC power supply with sufficient capacity and a low ripple. Example: Class 2 voltage source. UL1310 compliant. ③ Turn off the power supply to remove and insert the connector. ④... -
Page 8: System Configuration P7
System configuration This product is connected to the field bus (CC-Link) as a slave. Master Power SUP.(DC24V) CC-Link Remote I/O Local I/O ・ ・ Remote device Intelligent device The pressure proportional to the signal on the second The compress side is air is supplied from the first obtained. -
Page 9: Setting Of Dipswitch P8
Setting of dipswitch △ CAUTION ！ ① Turn off the power supply while setting the switch. ② If there is foreign matter or water droplets around the switch cover, clean it off before opening the cover. ③ Refer to the drawing below for the setting at the time of shipment from the factory. -
Page 10: Pressure Setting And Output Monitoring P9
■Setting of baud rate Baud rate 0(156kbps) 1(625kbps) 2(2.5Mbps) 3(5.0Mbps) 4(10Mbps) ■Setting of Hold/Clear This switch is selected to hold or clear the output pressure, when the communication error due to disconnection. Setting Switch1 Function NOTE Hold Hold the output pressure Clear Exhaust the output pressure Note: The hold pressure is set depending on the communication data(RY00～... -
Page 11: Communication Data Allocation P10
Communication data allocation Bellow shows in the case of node address "1". Output area Word data area Remote register Output word data ,…b RWw0 RWw1 Unused RWw2 Unused RWw3 Unused Output data occupies 4 words, but uses only the 1 word actually. -
Page 12: Maintenance And Inspection P11
Maintenance and inspection ■Turn off the power supply, stop the supplied air, exhaust the residual compressed air and verify the release of air before performing maintenance. ■Foreign matter caught in the inlet of piping or exhaust may interfere with normal operation.
