SMC Networks ITV1000-IL Series Operation Manual page 11

Process data output: 2 BYTE (base module --> device (ITV))
The product adjusts the pressure to the set value.
15 14 13 12
* Data is adjustable up to 120%F.S. (Max. guaranteed output pressure accuracy is 100%F.S.)
Pressure setting mode
The pressure can be set by sending input data from the base PLC to the regulator where the
full span is 12-Bit. Do not use values outside of the specification range (including Bit 13th to
15th). They are recognized as large values which could cause an error (Er1).
<Relationship between the set pressure (16-Bit) and output pressure>
Set pressure
Output pressure
Input data shall be entered from Bit 0 to Bit 12 of the 16-Bit process data (2 BYTE).
(When F_1=0%F.S. and F_2=100%F.S.)
(Ex.) When the output pressure is 100%, the set pressure value is 0x0FFF.
■ IO-Link parameter setting
●IODD file
IODD (I/O Device Description) is a definition file which provides all properties and
parameters required for establishing functions and communication of the device.
The IODD includes the main IODD file and a set of image files such as vendor logo, device
picture and device icon.
The IODD file is shown below.
Product Communication
No.
ITV*0*0
-IL*****
(230.4 kbps)
-********
*： yyyymmdd" indicates the file preparation date of the file. yyyy is the year, mm is the month
and dd is the date.
0
11 10 9
Set pressure value.
0x0000
0%
Process data size
speed
COM3 4-BYTE input /
2-BYTE output
8 7 6 5
(16Bit)
0x0FFF
100%
- 10 -
1
4 3 2 1
IODD file
SMC-ITV-IL-yyyy ㎜ dd-IODD1.1
BYTE
0 Bit
Value
※
