Detail setting mode
No
(1) Deactivate the key lock if necessary (see page 22).
(2) Press S-key for 2 seconds or more.
△ key
△ key
△ key
(3)
△ key
(4) In state of 3, press S-key for 2seconds or more.
(5) Return to (current) pressure display.
(6) Activate the key lock if necessary (see page 22).
Key operation and LED display
⇔
↑
▽ key
↓
⇔
▽ key
↑
▽ key
↓
⇔
↑
▽ key
↓
⇔
(displayed alternately)
Press S-key
To "GAIN" (refer to P27)
(displayed alternately)
Press S-key
To "SENSITIVITY" (refer to P28)
(displayed alternately)
Press S-key
To "ZERO CLEAR" (refer to P29)
(displayed alternately)
Press S-key
To "INITIALIZE" (refer to P30）
- 26 -
