- Page 1 Doc. No.DIT-69900-OM005-E PRODUCT NAME IO-Link/ELECTRO-PNEUMATIC REGULATOR MODEL / Series / Product Number ITV1000/2000/3000-IO* Series...
-
Page 2: Product Specifications
Doc.No.DIT-69900-OM005-E This is the operation manual for the IO-Link compliant ITV. For other contents which are not described in this manual, please refer to the operation manual for the standard product. １. Product Specifications Item Specified value Power supply voltage DC24 V ±10% F.S. -
Page 3: Communication Data
Doc.No.DIT-69900-OM005-E ４．Pressure setting method and output monitoring Pressure can be set by sending input data from the master PLC to the regulator where the F.S is based on a 12 BIT resolution. Do not operate the product outside of the specifications. <Relationship between set data and pressure>... - Page 4 Doc.No.DIT-69900-OM005-E Parameter index 0x0C Parameter name Device access lock In ITV for IO-Link, you can set "lock / unlock" for data storage function. Function Locking data storage function will invalidate data storage function. When backing up data storage (Parameter setting data read) or restoring (Overwriting parameter setting data) is instructed while data storage function is locked, the access rejection is answered.
- Page 5 Doc.No.DIT-69900-OM005-E Parameter index 0x43 Parameter name Sensitivity tuning function Function Changing the sensitivity will change the pressure correction operation near the set pressure point. When the sensitivity is increased, hunting may occur. When the sensitivity is decreased, hunting will be reduced, but the pressure correction will be reduced, so there may be a moderate pressure instability.
- Page 6 Doc.No.DIT-69900-OM005-E Parameter index 0x46(Zero adjusting), 0x47(Span adjusting) Parameter name Zero adjusting , Span adjusting Zero adjusting (hereinafter referred to as F_1) corresponds to set the Function minimum pressure, Span adjusting (hereinafter referred to as F_2) to set the maximum pressure. F_1 and F_2 have setting ranges of 0-90%F.S. and 10-120%F.S., respectively.
- Page 7 Doc.No.DIT-69900-OM005-E F_1=0x0665（40%） F_2=0x0999（60%） 50％ 50％ Process data(Input) The set pressure output 50% when the process date input 50% F_1=0x0800(50%) F_1=0x0665(40%) 50％ Process data(Input) The set pressure output 45% when the process date input 50% Fig.3 F_1 and F_2 usage example 5.3 Error Message Item Flashing...
- Page 8 Doc.No.DIT-69900-OM005-E Error code Error No. Name: Description ROM read / write error Control depends on the Hold/Clear setting. 0x5000 Internal diagnosis error Power LED turned ON Red. If the error is not corrected even after disconnecting the power supply, perform "Initialization”. The data of the target value has exceeded the Target value over range 0x6320...
- Page 9 Doc.No.DIT-69900-OM005-E Revision Correction concerning communication data, Product ID addition and correction by software modification. 0120-837-838 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 http://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. ©...
