Doc. No. ITV2-OM00118-A
P R O D U C T
N A M E
E/P Regulator
(PROFIBUS DP type)
MODEL/ Series/ Product Number
ITV1000/2000/3000/2090-PR* Series
● Install and operate the product only after reading the Operation Manual carefully and
understanding its contents.
● Specifically, read the safety instructions carefully.
● Keep this operation manual available whenever necessary.
Advertisement
Table of Contents
Related Manuals for SMC Networks ITV1000-PR Series
Summary of Contents for SMC Networks ITV1000-PR Series
- Page 1 Doc. No. ITV2-OM00118-A P R O D U C T N A M E E/P Regulator (PROFIBUS DP type) MODEL/ Series/ Product Number ITV1000/2000/3000/2090-PR* Series ● Install and operate the product only after reading the Operation Manual carefully and understanding its contents. ●...
-
Page 2: Table Of Contents
Contents Contents Safety Instructions Handling precautions Wiring method and LED indication System configuration Communication specification Setting of dipswitch Pressure setting and output monitoring Communication data allocation Maintenance and inspection - 1 -... -
Page 3: Safety Instructions P2
E/P Regulator Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) and other safety regulations. - Page 4 E/P Regulator Safety Instructions Caution 1. The product is provided for use in manufacturing industries. The product herein described is basically provided for peaceful use in manufacturing industries. If considering using the product in other industries, consult SMC beforehand and exchange specifications or a contract if necessary.
-
Page 5: Handling Precautions P4
Handling precautions △ Caution ！ If the power supply to this product is turned off due to a power failure during normal operation, the output on the secondary side will be held and air will flow continuously. If supply pressure to this product is interrupted or shut off, while the power is still on, the internal solenoid valve will continue to operate and a humming noise will be... - Page 6 △ Caution ！ Take following steps avoid malfunction due to noise. 1. Install a line filter etc. to the AC power line to reduce / eliminate power supply noise. 2. Avoid malfunction due to noise by installing this product and its wiring away from strong electric fields, such as those of motors and power cables, etc.
-
Page 7: Wiring Method And Led Indication P6
Wiring method and LED indication △ CAUTION ！ ① Proceed carefully, as incorrect wiring can cause damage. ② Use a DC power supply with sufficient capacity and a low ripple. Example: Class 2 voltage source. UL1310 compliant. ③ Turn off the power supply to remove and insert the connector. ④... -
Page 8: System Configuration P7
System configuration This product is connected to the field bus (PROFIBUS DP) as a slave. Master Power SUP.(DC24V) PROFIBUS DP Slave1 Slave2 ・ ・ DP equipment DP equipment The pressure proportional to the signal The compress on the second air is supplied side is from the first obtained. -
Page 9: Setting Of Dipswitch P8
Setting of dipswitch △ CAUTION ！ ① Turn off the power supply while setting the switch. ② If there is foreign matter or water droplets around the switch cover, clean it off before opening the cover. ③ Refer to the drawing below for the setting at the time of shipment from the factory. -
Page 10: Pressure Setting And Output Monitoring P9
■Setting the terminator Set PROFIBUS communication line terminator. With Terminator (at shipping) Without terminator Without terminator ・When the product is connected to the terminal of PROFIBUS communication line, be sure to set it to “with terminator”. Pressure setting and output monitoring Pressure setting can be done by sending input data using 12bit as F.S. -
Page 11: Communication Data Allocation P10
Communication data allocation Set target value (from PLC to ITV) Target value Resolution : 12bit (100%F.S.), Occupied byte : 2 Byte (O area) Target value (Lower 12 bits) (note) Monitor the output pressure. (from ITV to PLC) Output pressure Resolution : 12bit (100%F.S.), Occupied byte : 2 Byte (I area) Output pressure (Lower 12 bits) (note) -
Page 12: Maintenance And Inspection P11
Maintenance and inspection ■Turn off the power supply, stop the supplied air, exhaust the residual compressed air and verify the release of air before performing maintenance. ■Foreign matter caught in the inlet of piping or exhaust may interfere with normal operation.
