246 GPIO7
249 GPIO8
NOTES
1. "Alternate Function 1/2" takes effect only after software configuration.
1)
2. See Table 4 for more details about the symbol description.
If the GPIOs without interrupt function are configured as interrupt GPIOs, power consumption of the module will be increased. ("Y" means "interrupt function supported". "N" means "interrupt function not
2)
3.
supported".)
4. Pins 69 and 83 cannot be pulled up before power-up.
