Dataman -848PRO2 User Manual page 8

For general information, recommendations and directions about the ISP interface, see
the manual section: Common notes / ISP .
Description of ISP connector
H/L/read driver
pins 3, 5, 7, 9, 11, 13 of ISP connector
A)
drivers in programmer
H/L
Float
Read
Pull-up/
Pull-down
C)
drivers in programmer
H/L
Float
Read
Pull-up/
Pull-down
2 4 6 8 10 12
1 3 5 7 9 11
Front view at ISP connector.
pin of ISP
connector
RA1
RA2
RA3
pins 15, 16 of ISP connector
CC1
pin of ISP
connector
RC1
RC2
RA1 180R, RA2 1k3, RA3 22k,
RB1 10k, RB2 10k,
8
14 16 18 20
13 15 17 19
pin 14 of ISP connector
B)
drivers in programmer
RB1
D)
RD1
GND
E)
H/L
pin of ISP
VCC
connector
RB2
YES!
GND
pin of ISP
connector
pin of ISP
connector
CE1
RE1
