Table of contents

Introduction .............................................................................................................................. 4
DATAMAN-848PRO2 elements............................................................................................. 6
Manipulation of the programmed device................................................................................ 7
In-system serial programming using DATAMAN-848PRO2 .................................................. 7
Selftest and calibration check .............................................................................................. 10
Technical specification......................................................................................................... 11
Programming a device........................................................................................................... 16
Engineering mode................................................................................................................ 16
Production mode.................................................................................................................. 20
Software .................................................................................................................................. 23
Detailed description of the Graphical user interface with touch screen ............................... 23
Administration of the built in PC........................................................................................... 41
Troubleshooting and warranty.............................................................................................. 46
Troubleshooting ................................................................................................................... 46
If you have an unsupported target device............................................................................ 47
Warranty terms .................................................................................................................... 48
We continuously update our manual. You may find the latest version on our website
Conventions used in the manual
References to the control program functions are in bold, e.g. Load, File, Device, etc.
References to control keys are written in brackets <>, e.g. <F1>.
Terminology used in the manual:
Device
ZIF socket
Buffer
USB port
HEX data format
(www.dataman.com).
any kind of programmable integrated circuits or programmable
devices
Zero Insertion Force socket used for insertion of the target device
part of the memory or disk used for temporary data storage
type of PC interface port
format of a data file which may be read with standard text viewers;
e.g. byte 5AH is stored as characters '5' and 'A', which means
bytes 35H and 41H. One line of this HEX file (one record) contains
the start address and data bytes. All records are secured with a
checksum.
