1 Product Overview

Featuring leading 802.11ac Wave2, Ruijie RG-AP710 supports 2 spatial streams and delivers up to 300Mbps@2.4G
(802.11b/g/n) and 2 spatial stream and delivers up to 867Mbps@5G (802.11a/n/ac). The overall dual-radio, dual-band
performance speeds up to 1167Mbps per device, totally eliminating Gigabit wireless bottlenecks. AP710 is ideal for a
variety of scenarios, such as large-scaled campuses, governments, financial services, and enterprises.
1.1 Technical Specifications
Table 1-1 Technical Specifications of RG-AP710
Hardware Specifications
Radio
RF
Transmission
Protocol
Operating Bands
Antenna
Spatial Streams
Access Rates
Modulation
Receive Sensitivity
Maximum Transmit
Power
Transmit Power
Adjustment
Physical
Dimensions
(W x D x H)
Weight
Service Ports
2.4GHz: 2 x 2MIMO
5GHz: 2 spatial streams
Support concurrent 802.11b/g/n and 802.11a/n/ac.
802.11b/g/n: 2.4 GHz to 2.4835 GHz
802.11a/n/ac: 5.15 GHz to 5.35 GHz, 5.47 GHz to 5.725 GHz, 5.725 GHz to 5.85GHz
(Depending on which country the AP is installed)
Built-in antenna
2.4G supports 2 spatial streams, 5G supports 2 spatial
2.4GHz: up to 300Mbp
5GHz: up to 867Mbps
Total: up to1167Mbp
OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps
DSSS: DBPSK@1Mbps, DQPSK@2Mbps, and CCK@5.5/11Mbps
MIMO-OFDM: BPSK, QPSK, 16QAM , 64QAM and 256QAM
11b: -91dBm(1Mbps), -88dBm(5Mbps), -85dBm(11Mbps)
11a/g: -89dBm (6Mbps), -80dBm (24Mbps), -76dBm (36Mbps), -71dBm (54Mbps)
11n: -83dBm@MCS0, -65dBm@MCS7, -83dBm@MCS8, -65dBm@MCS15
11ac HT20: -83dBm (MCS0), -57dBm (MCS9)
11ac HT40: -79dBm (MCS0), -57dBm (MCS9)
11ac HT80: -76dBm (MCS0), -51dBm (MCS9)
20 dBm
(Depending on the country of use, laws and regulations.)
1 dBm
194 mm x194 mm x 37 mm
(7.64in x7.64in x 1.46in)
0.42 kg
One 10/100/1000BASE-T Ethernet port (PoE-capable)
Product Overview
streams
