Hardware Installation and Reference Guide

1 Product Overview

Ruijie RG-AP180 AP is designed for indoor scenarios in campuses, hotels, offices and residential buildings. Featuring a
concise design and easy deployment, the AP enables zero disruption to the interior finishes and offers the best solution
for scenarios with delicate interior design.
The dual-radio, dual-band AP supports the latest 802.11ax. And it delivers data rates of up to 574Mbps at 2.4G and
1.2Gbps at 5G with the maximum delivery rate totaling 1.77Gbps. The Wall AP provides four 10/100/1000Base-T LAN
ports and one 10/100/1000Base-T WAN port, delivering optimal wireless network coverage. RG-AP180 supports security,
radio frequency (RF) control, mobile access, Quality of Service (QoS) and seamless roaming. Plus, two power supply
modes are provided, so you can choose to power up the AP either by local or PoE power supply.
Teaming up with Ruijie RG-WS Wireless Controller Series, wireless data forwarding, high performance security and
access control can be accomplished with ease.

1.1 Technical Specifications

Table 1-1 Technical Specifications of RG-AP180
Hardware Specifications
Radio
Transmission
Protocol
Operating Bands
Antenna
Spatial Streams
Max Throughput
Modulation
Receive Sensitivity
2.4G: 2 x 2MIMO
5G: 2 x 2MIMO
2.4G : 802.11b/g/n/ac/ax
5G: 802.11a/n/ac/ax
Support concurrent operation of 802.11ax and 802.11a/b/g/n/ac.
802.11b/g/n/ac/ax: 2.4 GHz to 2.483 GHz
802.11a/n/ac/ax: 5G: 5.150 GHz to 5.350 GHz, 5.47 GHz to 5.725 GHz, 5.725 GHz to 5.85GHz
(Country-specific)
Built-in antenna
4 streams
2.4G: up to 574Mbps
5G: up to 1.2Gbps
Up to 1.77Gbps per AP
DSSS: DBPSK@1Mbps, DQPSK@2Mbps, and CCK@5.5/11Mbps
OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps
MIMO-OFDM: QPSK, 16QAM, 64QAM, 256QAM and1024QAM
11a: -91dBm(1Mbps), -90dBm(5Mbps), -87dBm(11Mbps)
11b/g: -89dBm(6Mbps), -82dBm(24Mbps), -78dBm(36Mbps), -72dBm(54Mbps)
11n: -85dBm@MCS0, -67dBm@MCS7, -67dBm@MCS7
11ac: VHT20: -85dBm(MCS0), -62dBm(MCS8)
11ac: VHT40: -82dBm(MCS0), -57dBm(MCS9)
11ac: VHT80: -79dBm(MCS0), -53dBm(MCS9)
Product Overview
·
