Hardware Installation and Reference Guide
Max Transmit Power
Transmit
Power
Adjustment
Dimensions
(W x D x H)
Weight
Service Ports
Management Ports
LED Indicators
Power Supply
Power Consumption
Bluetooth
Temperature
Humidity
Installation
IP Rating
Safety Standards
EMC Standards
Radio
MTBF
1.2 Product Image
The AP provides two radio ports, one 10/100/1000Base-T Ethernet WAN port, and four 10/100/1000Base-T Ethernet LAN
ports.
Figure 1-1 Image of RG-AP180
11ax: HE80: -79dBm(MCS0), -53dBm(MCS9),-52dBm(MCS11)
≤ 100mw (20dBm)
(Depending on the country of use, laws and regulations.)
1 dBm
86mm x 116mm x 40mm
≤ 0.3kg
Four 10/100/1000Base-T LAN ports
One 10/100/1000Base-T WAN port (PoE and PoE+ capable)
One Micro USB port for console management
One indicator
Local power supply: DC 12V/1A
PoE: IEEE 802.3af/802.3at-compliant (compatible).
< 10W
Bluetooth 4.0
iBeacon
Operating: -10° C to 45° C (14° F to 113° F)
Storage: -40° C to 70° C (-40° F to 158° F)
Operating: 5% to 95% RH (non-condensing)
Storage: 5% to 95% RH (non-condensing)
Wall mount
IP41
GB4943
EN/IEC 60950-1
GB9254
EN301489
EN50121
EN50155
China Radio Transmission Equipment Type Approval Certificate
EN300 328
EN301 893
> 250,000H
Product Overview
·
