Assembly
5.2
Installing the charged battery into the LED light source:
Fig. 4 View on light source from above before battery change
Fig. 5 Opened light source
Top-Line Video Endoscope

Mounting the Light Source

Install batteries by rotating battery cover dial to position shown, and pulling cover off, see
Dial
Remove the cap of the light source.
Insert batteries in the correct orientation according to the battery polarity labels on outside and inside of
light source.
Light source
Battery
Replace the cap of the LED light source again.
Cap
Fig. 4.
