Operation
6.11
Make sure the gold contacts are facing away from the video display.
Fig. 51 Inserting the SD memory card
i
The card is in the slot now.
The card will spring out far enough to remove.
i
Top-Line Video Endoscope

Inserting SD Memory Card

Insert the SD memory card into its slot, see
Push the card in gently, as far as possible and then release.
Do not press the card with violence and with the contacts in wrong direction into the slot.
To remove the card, push it in a little and release to take out the card again.
Do not remove the SD memory card during image capture operations. This may result in a data loss and
a damage of the memory card.
Fig. 51.
