Instructions for Operation

7.4
Light source intensity is at a low setting.
Probe tip may be too far from object.
If using a detachable tip adapter, the probe tip may
not be properly attached.
The lenses or glass windows may be dirty.
Light source capacity may be insufficient for ap-
plication.
8.
8.1
Do not remove the SD memory card during image and video capture. This can cause data loss and damage
to memory card.
i
8.2
i
Top-Line Video Endoscope

Image not Bright Enough

Instructions for Operation

SD Memory Card

We recommend a 80x SD card for best video quality, see Chap. 3.1.

Cleaning

Use cotton swabs and lens cleaning fluid or isopropanol (rubbing alcohol) for cleaning the optics.
Clean the display with a clamp cloth only.
Do not use chemical solvents, commercial glass cleaner or other cleansing agents.
Turn to maximum intensity.
Move probe tip closer to object.
Detach tip adapter and reinstall.
Clean glass surfaces on probe tip, light guide
connector and the eyepiece with alcohol and
cotton swabs (or soft cloth), see Chap. 8.2.
Also clean detachable tips if being used, see
Chap. 8.2.
