Operation
6.4
A control lever controls the right/left movements and the other control lever the up/down movements at the
4-way configuration.
Do not angle the flexible probe or the probe tip with violence.
NOTICE
> Damage of the flexible probe and/or the probe tip
Locking
Fig. 12 Controlling the probe tip by control lever
Top-Line Video Endoscope

Controlling the Probe Tip

Enable the locking if necessary, to hold the probe tip in the position as soon as the video-endoscope is
in the viewing position.
Control lever
Page 24
