General Telephone Functions - Commend C-G8-S0 Manual

G8-S0/G3-S0-I

General Telephone Functions

Initiate Dialling of
For an call from the telephone to the Intercom system, it is possible to configure, that button 0 (at the
respective called station) is dialled automatically. This feature can be used e.g. in combination with the
following Intercom functions:
 Call Request to a Central Control Desk
(the call lasts until it is taken over)
 Triggering of the Direct Dialling function
(e.g. call to a station, initiation of a predefined conference etc.)
Configuration CCT 800
Interfaces > S0 > tab Common
 Activate the checkbox Dial 0 at incoming call for the telephone interface.
For configuration of call requests and direct diallings, see current version of the manual "PRO 800".
DTMF After-Dial Mode
In standard (in PABX mode), 8 seconds after entry of the last digit of the respective telephone number,
the after-dial mode is switched automatically from DTMF dialling to "Intercom dialling" (i.e. possibility
for after dialling in the Intercom system).
Note: But via dialling 77, it is possible to activate the DTMF dialling mode again, see also
Dialling of 0 at Incoming Calls" on page 33
Via configuration in CCT 800 it is possible, to deactivate the possibility for after dialling in the Intercom
system – i.e. the after-dial mode is switched fix to DTMF dialling.
Configuration CCT 800
Interfaces > S0 > tab Common
 Activate the checkbox Fix DTMF After-Dial Mode for the telephone interface.
Blocking Incoming Calls
It is possible to block calls from the telephone net to the Intercom system.
Configuration CCT 800
Interfaces > S0 > tab Common
 If the checkbox No hook-off at incoming call is activated, it will not be possible to call from a tele-
phone over the telephone interface, into the Intercom system.
1.1/1010
0
at Incoming Calls
Telephone Interface
see "Initiate
33
