Maintenance
Replacing a Hospitality Integrated Voice Services card
1. Disable the Hospitality Integrated Voice Services card by accessing LD 32 and
2. Remove the Hospitality Integrated Voice Services card from its card slot.
3. Remove the PC Card from the faulty Hospitality Integrated Voice Services card.
4. Transfer the PC Card to the new Hospitality Integrated Voice Services card.
5. Transfer the Security Device from the faulty Hospitality Integrated Voice Services
6. Enable the new card by executing the ENLC l s c command. For Avaya CS 1000
7. Configure the newly-installed Hospitality Integrated Voice Services card.
8. Package the faulty Hospitality Integrated Voice Services card and ship it to the repair
96 Hospitality Integrated Voice Services Fundamentals
executing the DISC l s c command, where l is the loop, s is the shelf or module,
and c is the card in the module. For Avaya Communication Server 1000 (Avaya CS
1000) systems, execute the DISC s c command.
Transferring the PC Card to the replacement Hospitality Integrated Voice Services
card moves all software, configuration, and records to the replacement Hospitality
Integrated Voice Services card.
card to the replacement Hospitality Integrated Voice Services card.
Note:
The replacement Hospitality Integrated Voice Services card re-uses the keycode.
The keycode is still on the PC Card that was removed from the faulty Hospitality
Integrated Voice Services card.
systems, execute the ENLC l s c command.
center.
Note:
When replacing the PC Card, it is important to back up the data on the PC Card
so that there is no need to re-enter the data. For instructions on backing up the
data, refer to Archive Database
Comments? infodev@avaya.com
on page 80.
