Installation and configuration
Connecting Ethernet adapter to customer PC when no LAN exists
1. Check the installation of the Ethernet adapter on the I/O panel as described in
2. Plug the modular cross-connect cable RJ-45 plug into the RJ-45 jack on the
3. Plug the RJ-45 plug at the other end of the modular cross-connect cable RJ-45
Figure 7: I/O connector bracket connection
connection to the Hospitality Integrated Voice Services card, the maintenance terminal, the
LAN, and PC connections
52 Hospitality Integrated Voice Services Fundamentals
Installing an Ethernet adapter onCabinet tip/ring connector
Ethernet adapter.
See Figure 7: I/O connector bracket connection
The LED on the Ethernet Adapter lights if a proper connection is made. If it
the LED does not light, re-connect the cable.
Refer to Table 16: RJ-45 cross-over (Ethernet) cable pinouts
RJ-45 cross-over cable pinouts.
Table 16: RJ-45 cross-over (Ethernet) cable pinouts
Pin Number
1
2
3
4
5
6
7
8
cable into the PC.
Comments? infodev@avaya.com
Signal Pin Number
TX+ 3
TX - 6
RX+ 1
--- 4
--- 5
RX - 2
--- 7
--- 8
on page 53 illustrates the I/O connector bracket
on page 49.
on page 53.
on page 52 for the
Signal
RX+
RX -
TX+
---
---
TX+
---
---
