RJ45 Ethernet
connector
A remote maintenance terminal can be connected by connecting the NTBK48AA cable to a
modem. See
illustration.
Follow the steps in
to connect a remote maintenance terminal using a modem.
Connecting the remote maintenance terminal using a modem
1. Check the installation of the Ethernet adapter on the I/O panel (see
2. Check the installation of the NTBK48AA cable to the DB-9 male connector on the
3. Plug the terminal cable 25-pin female connector into the 25-pin male connector
4. Plug the DB-25 male connector at the other end of the terminal cable into the DB-25
5. Plug the DB-25 male connector of the null modem adapter into the DB-25 female
6. Plug the modular modem cable RJ-11 plug into the RJ-11 jack on the modem.
7. Plug the other end of the modular modem cable RJ-11 plug into the RJ-11 jack on
Remote multi-terminal connection through the LAN
The Hospitality Integrated Voice Services card can be accessed from multiple terminals
through Telnet over the LAN. See
refer to Connecting the Ethernet adapter to the LAN
Note:
The Hospitality Integrated Voice Services card cannot be accessed through Telnet over the
LAN until the LAN parameters for the Hospitality Integrated Voice Services card are
configured first.
Initial configuration of the Hospitality Integrated Voice Services card, including configuring
the LAN parameters, requires a serial terminal connection to the card.
Hospitality Integrated Voice Services Fundamentals
Pin Number
5
1
2
3
6
Figure 7: I/O connector bracket connection
Connecting the remote maintenance terminal using a modem
Ethernet adapter onCabinet tip/ring connector
Ethernet adapter.
(labeled Port 0) of the NTBK48AA cable.
female connector of the DB-25F/DB-25M null modem adapter.
connector on the modem.
the wall, for PSTN access.
Configuring LAN parameters for a direct connection to a PC
Signal Description
GND (Ground)
LAN_Tx+
LAN_Tx -
LAN_Rx+
LAN_Rx -
Figure 7: I/O connector bracket connection
on page 51 for instructions.
on page 53 for the connection
on page 49).
on page 53 and
