Engineering guidelines

Access to the BUI

Guest and staff access parameters are configured through the BUI. The BUI is provided by
the Hospitality Integrated Voice Services PC Card. Access to the BUI is made only through the
intranet with a web browser on a PC.
LAN characteristics
Ethernet implementation over the Hospitality Integrated Voice Services card has the following
LAN characteristics:
• The Hospitality Integrated Voice Services card Ethernet connection is separated from the
external LAN traffic by a firewall.
• The Ethernet adapter options for the Hospitality Integrated Voice Services card are:
- NT5D52AC for the IPE module
- NT5D52BC for Media Gateway or Media Gateway Expander
• The network administrator assigns the IP address for the Hospitality Integrated Voice
Services card using the CLI during initial configuration.
Web server characteristics
The web server houses the BUI and already resides on the Hospitality Integrated Voice
Services card. Setting up the embedded web server is simple and does not require any external
equipment. Assign an IP address to the Hospitality Integrated Voice Services card and access
the web server by pointing a web browser to the IP address.
Web browser characteristics
The BUI requires one of the following web browsers on a PC:
• Netscape Navigator 4.5 (or later)
• Microsoft Internet Explorer 4.01 (or later) with Service Pack 1 (SP1)
To access the BUI, open a web browser and enter the address of the Hospitality Integrated
Voice Services card web server in the URL field.
