1.9 Installation Location

When connecting the vacuum pump to your cutting plotter, please refer to the following diagram.
CAUTION
The exhaust from the vacuum pump is hot, so do not place anything flammable near the exhaust port.
Failure to observe this precaution could cause a fire.
FC2250-60VC
CA2294-01
Vacuum pump
FC2250-120VC
FC2250-180VC
CHECKPOINT
A vacuum pump is not provided.
FC2250-UM-251-9370
Hose band
CA2294-03
Hose band
1-10
Durable flexible hose
CA2294-02
Connect to the power outlet
CA2294-01
Hose band
Durable flexible hose
Vacuum pump
Hose band
CA2294-03
CA2294-02
1. INTRODUCTION
Connect to the
power outlet
